Handheld Optical Power Meter Gao C0260006 - Canada

Overview - Handheld Optical Power Meter This optical power meter

features a wider power measurement range and a higher frequency range

than other similar devices.

It defines a new industry standard for

installation, test and maintenance of both single and multimode networks

and cables.

The handheld optical power meter is calibrated over a large

number of wavelengths to enable power measurements to be made on a wide

range of single mode and multimode fiber optic cable systems.

Combined

with a laser source, it is commonly used in the testing of fiber optic

networks and for CATV installation and maintenance, LAN and WAN testing

and quality assurance and acceptance testing.

Key Features - Handheld Optical Power Meter

•Multi-wavelength precise measurement

•Absolute power measurement

•Relative power measurement

•SC, FC, ST and LC connector (universal)

•Real time clock function

•Low voltage warning

•Automatic power off after 10 minutes without operation

•High resolution LCD display

•USB interface

•Works continuously for more than 30 hours on a charge

•Energy saving design

Technical Specifications - Handheld Optical Power Meter

Wavelength Range

800 nm to 1600 nm

Detector Type

InGaAs

Standard Wavelength

850 nm, 980 nm, 1310 nm, 1550 nm

Power Testing Range

-50 dBm to 26 dBm

Uncertainty

± 5%

Resolution

Linearity: 0.1% Logarithm: 0.01 dBm

Connectors

Universal or FC, ST, SC

Memory Capacity

200 groups data items

Working Temperature

0 °C to 40 °C

Storage Temperature

-10 °C to 60 °C

Weight

210 g

Dimension

160 mm ×76 mm ×28 mm

Power

3.7 V3000 mAh rechargeable lithium battery

Battery Working Duration

No less than 175 h

Low Voltage Warning

≤ 3.4 V

Auto Power Off Time

10 min

Automatically Backlight Off

60 s

Handheld Optical Power Meter Gao C0260006
