High Performance Fast Survey Tractor Based Rtk Gps - China

Electrical

Power 6V to 28V DC external power input

Power consumption ≤3.5W

Automatic switching between internal power and external power

Rechargeable, removable 7.4V, 5000mAh Lithium- ion battery in internal battery compartment

Internal Battery Life

Static 12hours

RTK rover ( UHF/ GPRS/ 3G) 8- 10 hours

RTK base 8 hours

I/ O Interface

1 xBluetooth, NFC

1 x standard USB2.0 port

1 x TNC antenna connector

1 x RS232 serial port

1 x DC power input ( 5- pin)

Tilt Survey System

Electronic Bubble

COMMUNICATION

Network Communication

Fully integrated, fully sealed internal WCDMA, compatible with GPRS, GSM

Wifi frequency is 2.4G, supports 802.11b/ g/ n protocol

Network RTK ( via CORS) range20- 50km

HI- TARGET Internal UHF Radio( Standard)

Frequency: 450~470MHz with 116 channels

Transmitting power: 0.5W, 1W, 2W adjustable

Transmitting speed: 9.6Kbps, 19.2Kbps

Working range: 3~5km typical, 8~10kmoptimal

Pacific Crest XDL Micro Internal UHF Radio

Frequency: 403~473MHz

Transmitting power: 0.5W, 2W adjustable

Transmitting speed: Up to 19.2Kbps

Support most of radio communication protocol

Working range: 3~5km typical, 8~10km optimal

HI- TARGET External UHF Radio ( Standard)

Frequency: 460MHz with 116 channels

Transmitting power: 5W, 10W, 20W, 30W adjustable

Working range: 8~10km typical, 15~20km optimal

Pacific Crest ADL Vantage Pro External UHF Radio

Frequency: 390~430MHz or 430~470MHz

Transmitting power: 4W to 35W adjustable

SYSTEM CONFIGURATION

System

Data storage: 16GB Internal storage ( Support up to 32GB external SD card)

Record GNS and RINEX format simultaneously

Data Formats

1Hz positioning output, up to 20Hz

CMR: CMR, CMR+, sCMRx input and output

RTCM: RTCM 2.1, 2.3, 3.0, 3.1, 3.2 input and output

Navigation outputs ASCII: NMEA- 0183 GSV, AVR, RMC, HDT, VGK, VHD, ROT, GGK, GGA, GSA, ZDA, VTG, GST, PJT, PJK, BPQ, GLL, GRS, GBS

Navigation outputs binary: GSOF
