Scaffolding Fasteners Testing Machine - China

Introduction

l diameter of Ø42.4mm, Ø48.3mm, Ø51.0mm steel pipe used in scallfolding and single-line coupler, double-line coupler, fully coupler steel pipe, structural steel overhang steel pipe and fully coupler steel pipe scaffolding, well frame, form board supporting frame, coupler made of forging casting iron or casting steel for architectural, house, administrational, road, water conservational, bridge, dam, chemical, metallurgy, coal, and ship engineering.

l bowl coupler type of steel pipe scaffolding, steel pipe scaffolding frame used in form board supporting board.

l wheel button type, round plate type and insert card type of scaffolding structural component.

l aluminium pipe scaffolding, rapid setting aluminium alloy scaffolding structural component, insulative rapid setting scaffolding and structural component.

l scaffolding component and parts.

l test and reseraching for anti-skiding, anti-breaking, torsion rigidity, tensile, and compression with right angle coupler, rotating coupler, jointing coupler, bottom seating.

l test and researching for strength of upper bowl coupler, lower bowl coupler welding, jointing of cross bar, welding strength of jointing of cross bar, compression strength of adjustable seating.

l tensile testing and researching for tension with plug.

l testing and researching with coupler component (standing pole, mandril, slanting support, supporting seat, adjustable seating, adjustable seating, adjustable supporting, bowl coupler jointing)

l tensile, compression and bending test with varety of material by adding gripper.

l tensile, compression and bending test with variety of rubber, plastic, film and other nonmetal material

l test with variety of metal, thin metal, wire, fine wire, fiber, elastomer, foam.

l test with textile, food, medcine, cosmetic, biological material.

l tensile, peeling and welding strength test with electronic component.

l test with wooden, paper, film production and other nonmetal material.

l strain relaxation and adhesive strength test.

Important specification

STM100/120 100KN/120KN scaffolding testing machine

1

Max.

test force

100KN/120KN

2

Grade of testing machine

Grade of 0.5/1

3

Measuring range of testing force

0.4%~100FS(grade of 0.5) /1%~100%FS(grade of 1)

4

Relative error of indicating value of test force

Between ±0.5% (grade of 0.5) / ±1.0% (grade of 1)

5

Resolution of test force

1/±300000F.

S(resolution is not changed in fully stroke)

6

Measuring range of deformation

0.2%~100%

7

Adjusting range of force controlled speed

0.005%-5%FS/S

8

Controlling precision of force controlled speed

When speed is smaller than 0.05%FS/s, between ±1% of setting value

When speed is larger than 0.05%FS/s, between ±0.5 % of setting value

9

Adjusting range of speed for deformation

0.005%~5%FS/S

10

Controlled precision of speed for deformation

When speed is <0.05%FS/s, between ±1% of setting value

When speed is ≥0.05%FS/s, between ±0.5 % of setting value

11

Adjusting range of speed for displacement

0.001~600mm/min (cutomized high speed system: 0.001~2000mm/min)

12

Controling precision of speed for displacement

Between ±0.2%of setting value

13

Controling range of Constant force, deformation and displacement

0.5%~100%FS

14

Control precision for constant force, deformation and displacement

When setting value is ≥10%FS, between ±0.5%, When setting value is <10%FS, between ±1%.

15

Effective test span

500mm

16

Moving stroke of transom

1200mm

17

Torsion displacement of steel pipe of scaffolding

1000mm

18

voltage

~220V±10%, 50Hz(reliable landing)

19

Rate of machine

2.0KW

20

Size of loading frame

2300*560*2150mm

21

weight

≈800KG
