Rdh250 110 Butt Fusion Welding Machine - China

RDH－250/110 Hydraulic Butt Welding Machine

Application:

Suitable for butt fusion welding of plastic pipes and fittings made of PE, PP, and PVDF in construction site or workshop.

Features:

1 - consists of basic frame, heating plate, planning tool, and support (for planning tool & heating plate) 2 - Removable PTFE coated heating plate with separate temperature control system.

3 - Electric milling cutter with reversible double cutting edge blades.

4 - Low starting pressure ensures reliable welding quality of small pipes.

5 - Hydraulic unit provides welding machine with compressing power.

6 - It is made of lightweight and high strength material; light weight, simple structure and easy to operate

7 - Separate two-channel timer shows time in soaking and cooling phases.

8 - High-accurate and shockproof pressure meter indicates clearer reading.

Technical parameter:

 Welding ranges: plastic pipes: 110mm－250mm

(110mm—125mm—140mm －160mm－180mm－200mm� ��225mm－250mm)

 Extended to 110mm－250mm

 Ranges of application: PE, PP and PVDF

 Working voltage: ～220V ±10%, 50Hz

 Total power: 3.95 kW, including: planning tool：1.1 kW, heating plate：2.1 kW, hydraulic unit motor: 0.75kW  PTFE coated heating plate, adjustable knob for temperature control, difference in heating plate surface temperature ≤±7°.

 Environment temperature: －10° ～ 45°

 Electronic count-down timers for heating and cooling time.

 Whole machine consists of basic frame, heating plate, planning tool, hydraulic unit and support (for planning tool & heating plate) Technical data:

Model RDH250

Welding ranges 110mm—125mm—140mm－1 60mm－180mm－200mm－22 5mm－250mm

Ranges of application PE, PP and PVDF

Heating Plate Max.

Temp.

270℃

Temp.

Deviation in surface ±5°

Working voltage ～220V ±10%, 50Hz

Environment temperature －10° ～ 45°

Heating Plate Power 2.1 KW Planning Tool Power 1.1 KW

Hydraulic unit Power 0.75 KW

Total Power 3.95 KW

Net Weight 143 KGS

Basic Frame Dimension 995×600×555

Support Dimension 610×590×670

Hydraulic unit Dimension 690×490×540
