Chest Drainage Tester - China

The thoracic drainage tester is widely applied in the medical field, mainly used for monitoring and evaluating the performance of thoracic drainage devices and the thoracic drainage situation of patients.

The following is a detailed introduction to the main uses, compliance standards, and technical parameters of the thoracic drainage tester: Main Uses

Monitoring and Assessment: The thoracic drainage tester can comprehensively monitor and assess thoracic drainage, covering multiple key indicators such as drainage volume, drainage speed, and the pressure in the drainage tube.

The accurate measurement and monitoring of these data help doctors promptly understand the changes in patients' conditions, thus enabling them to make more precise treatment decisions.

Enhancing Treatment Efficacy: By providing accurate data and references for clinicians, the tester contributes to improving the treatment efficacy and recovery rate of patients.

Doctors can carry out personalized treatment for patients based on the data provided by the tester and optimize the treatment plans.

Surgical Monitoring and Condition Evaluation: After thoracic drainage surgery, the tester can promptly monitor the drainage status, assisting medical staff in understanding the surgical outcome and guiding further treatment.

Meanwhile, through continuous monitoring of patients' physiological parameters, the tester helps medical staff evaluate patients' conditions and formulate more reasonable treatment plans.

Adaptability Testing: Some thoracic drainage testers are also equipped with an adaptability testing function, which is used to assess the adaptability indicators of thoracic drainage devices, ensuring the stability and reliability of the devices when simulating changes in thoracic pressure.

Standards

The design, manufacture, and use of thoracic drainage testers should comply with relevant medical industry standards to ensure the accuracy and reliability of test results.

Common compliance standards include YY/T 0583.1 - etc.

Technical Parameters

Pressure Range: The pressure range of the tester is usually wide to adapt to the needs of different thoracic drainage devices and patients.

For example, the pressure range can reach -10020kPa (-10010kPa, depending on the specific model), with an accuracy of 0.5%FS.

Flow Range: The flow range is also one of the important technical parameters of the tester, used to evaluate the drainage capacity of thoracic drainage devices.

For instance, the flow range can be 0 - 1000mL/min, with the same accuracy of 0.5%FS.

Air Source Pressure and Interface: The tester is typically equipped with an air - source interface for connecting to air - source equipment (such as an air compressor) to supply the required air pressure for testing.

The air - source pressure generally does not exceed 0.7MPa (the user needs to provide the air source), and the air - source interface is usually a Φ6mm or Φ8mm polyurethane tube.

Power Supply: The power supply of the tester usually supports a wide voltage range, such as AC100 - 240V, 50/60Hz, to adapt to the electrical standards of different countries and regions.

Operation Interface and Display: The tester is usually equipped with a color touch - screen operation interface, supporting Chinese - English switching (or other languages).

The interface is clear and straightforward, making it easy for medical staff to operate and use.

Meanwhile, the tester also has real - time data display and recording functions, facilitating medical staff to view and analyze test results.

External Dimensions and Weight: The external dimensions and weight of the tester vary depending on the model, but it is generally designed to be compact and lightweight for easy portability and use.

For example, the external dimensions may be 390mm(L)×410mm(W)×190mm (H) (the specific dimensions depend on the model), and the weight is moderate, which is convenient for medical staff to move and operate.

Other Functions: Some testers are also equipped with additional functions such as automatic calibration, fault diagnosis, data export, and printing to improve testing efficiency and convenience.
