Explosion Proof Axial Flow Fan - China

Explosion proof Axial Flow Fan

Specifications

1 - Ex-mark: Exd II BT42 - Rated voltage: AC220V/380V3 - Wind cylinder : Superior quality steel plate

4, could install with shelf as per your need5 - Main shaft revolution: 1450 r/min6 - power: 0.18-1.1kw7 - air volume: 2280-10320m3/h

Application

1, Designed forExplosive atmosphere Zone 1, Zone 2

2, Designed forGroups IIA, IIB, IIC, Temperature classes T1~T4

3, Designed for sites with explosive atmosphere, such as petroleum exploitation, refinery, storage, chemistry, medicine, military facilities, etc.

Features

1, Explosion proof axial flow fan is composed of explosion proof motor, fan blade , wind cylinder, etc.

2, Wind cylinder is welded of superior quality steel plate, die casted fan of Aluminium alloy

with high pressure electrostatic plastic-sprayed surface.

3, Mounting mode has four ways can be chosen: Bracket type, pipe type, post type, fixed type.

4, Steel pipe wiring and cable wiring.

Technical parameters

1, Explosion protection: Exd IIBT4

2, Rated voltage: AC 220/380V

3, Main shaft revolution: 1450 r/min

4, Corrosion proof grade: WF1

5, Ingress thread specification: G3/4'

6, Cable's outer diameter: 9mm~14mm

7, Compliance with: GB 3836.1, GB 3836.2, IEC60079-0, IEC60079-1
