Femoral Condyles Components Fatigue Performance Test System - China

Standard

ASTM WK51649: Specifies fatigue testing protocols for metallic femoral components in total knee arthroplasty, including F-N curve generation and 10⁷-cycle endurance verification.

ISO 14879-1: Additional compliance for fatigue testing of total knee joint prostheses.

Adaptive Protocols: Customizable for emerging standards in additive-manufactured and coated implant evaluation.

Technical Parameters

Parameter Specification

Max.

Dynamic Force ±5.000 N (10.000 N peak optional)

Frequency Range 0.1–30 Hz (0.01 Hz increments)

Load Ratio (R) 0.1–10 (adjustable)

Axial Displacement ±20 mm (0.1 μm resolution)

Torque Capacity ±30 Nm (0.01 Nm resolution)

Temperature Range -20°C to +50°C (environmental chamber)

Humidity Control 10–95% RH (non-condensing)

Data Sampling Rate 100 kHz (synchronized across 16 channels)

Power Requirements 220V/110V ±10%, 50/60Hz, 2.500W

Dimensions (W×D×H) 1.600 × 1.100 × 2.100 mm

Weight 850 kg (including environmental chamber)

Noise Level <68 dB (A-weighted)
