Medical Injection Needle Rigidity Test Device - China
price: contact company for price
Standard
GB 18457-2001 This standard mandates precise control over needle wall thickness (normal, thin, ultra-thin) and rigidity performance, directly impacting patient comfort by minimizing pain during injections.
Technical Parameters
Parameter Specification
Deflection Measurement 0–5mm, Accuracy ±0.01mm
Load Capacity 5.5–60N, Accuracy ±0.1N
Span Adjustment 0–55mm, Accuracy ±0.5mm
Needle Compatibility 0.3mm–3.4mm (Normal/Thin/Ultra-Thin Wall)
Loading Speed 1mm/min ±0.1mm/min
Dimensions 460mm × 340mm × 400mm
Weight 25kg
Power Supply AC 220V/50Hz or Customized
Warranty 1 Year + Lifetime Standard Upgrades
Company Contact:
- Posted By: Standard International Group (HK) Limited
- Phone: 18355172336
- Address: No.2578 Gu Dai road, Min Hang district, Shanghai, shanghai , Shanghaai , China
- Email:
- Website: https://www.standard-groups.com/en/
Published date: November 24, 2025
- Business Description: Standard Groups is an integrated supplier specialized in providing material test instruments and “The Whole Laboratory Program” solutions.
The main products cover many areas: Textile and Apparel, Leather and Footwear, Flammability Testing, Filter Material Testing, Automotive Interior, Toy Testing, Non-woven and Geo-membrane, Carpet Testing, Luggage/Furniture/Office Furniture Testing, Material and Parts of Automotive, Weathering and Light Stability Testing, Ovens and Environmental Testing Chambers, Salt Fog Chambers, Materials Testing Machines, 3D Body Scanning and Manikin, Air Quality Monitoring and Measurement, Package Material Testing, Electrical Safety Testing, Optical and Spectroscopy Instruments, Lighting and Color Assessment, Microscopy and Legal Inspection, and relative testing services.
