Paper Plastic Composite Films Coefficeint Of Friction Testing Machine - China

COF-2002 Coefficient of Friction Tester is used to accurately measure static and dynamic coefficient of friction of plastic films, sheeting, hair, catheter, paper, paperboard, wood, break pad, tyre, windshield wiper, conveyor belt etc.

other relevant materials with high accuracy(better than 0.5 of FS)

Standard:

ASTM D1894, TAPPI T816, ISO 8295, GB 10006, GB/T 17200, Main feature:

1: 2 patents and 2 counts of software copyright registration.

2: Designed based on ASTM, ISO, GB standards.

3: Highly accurate load cell.

4: Test speed can be set freely through touch screen.

5: Keyboard + touch screen operation.

6: Real color TFT LCD display.

7: Micro-printer built-in.

8: DB9 RS232 communication port.

9: Professional computer software support.

10: Wide range sample thickness test is available.

11: Sled mass can be set through touch screen.

12: Static coefficient, dynamic coefficient test.

13: Overload, limit position protection.

14: One touch to start a new test.

15: Various non-standard test is available.

16: Various analysis functions.

17: Low power consumption.

18: Ethernet communication module is optional.

19: LMIS system is optional(Laboratory Management Information System), easy to share test data.

Technical indexes:

Load cell range 5N, 10N, 30N, 50N, 100N customization

Accuracy 0.5

Max travel distance 400mm

Sled mass 200g, 500g customization

Test speed 0~300mm/min

Sample thickness 30mm optional

Power supply AC220V 60Hz

Power consumption 21W

Dimension 650mm(L) *340mm(B)* 210mm(H)

Net weight 22kg
