Smt Loader For Loading Pcb Storage Racks Used In Smd Production Line - China

SMT Loader for loading PCB storage racks used in SMD production Line

Product Details Automatic Unloader: 1 - Special aluminum alloy mechanism, more clearly understand MAGAZINE operation state.

2 - Stable casting platform structure design, improve the stability of the equipment.

3 - PLC controlled, multi-function electrical circuit and procedural design, stable performance to ensure smooth and smooth production line.

4 - Standard SMEMA.

5 - Can be customized according to customer requirements inventory number.

6 - Three- point positioning, up and down pneumatic clamping, ensuring accurate location of material box.

7 - Designed gas circuit for transmit PCB smoothly and stably.

8 - Warranty: Major parts comes with 1 year warranty.

Automatic Loader

Specification / Type LD-M-GL LD-L-GL LD-XL-GL LD-XXL-GL

Description This equipment is used in the SMD production line for load the PCB board magazine storage racks.

PCB rack Size(mm) (L*W*H) 355x320x263 460×400×565 535×460×570 535x530x570

355x320x363

355x315x580

355×320×563 400x320x563

Transport Height(mm) 900±20(std)

Transmission Time 6.0 sec

Power Supply AC 110/220V±10V, 50/60HZ

Machine Size(mm) (L*W*H) 1380*750*1550 1600*850*1550 1800*910*1250 1800*975*1250

Weight(KG) 190 210 240 260

Interface Language English

Signal Interface Standard SMEMA online signal

Transmission Direction Left to Right (optional: Right to Left)

contact：jack(@)goldl andsmt.

com
