Spectrophotometer Chamber - China

Standard

CIE No.

15 - ISO 7724-1: Meets international colorimetry and spectral measurement standards.

GB/T 3978 - GB 2893: Adheres to Chinese national standards for color accuracy.

Product Advantages

1 - Dual-Mode Precision CMOS Dual-Path Sensor: Simultaneous SCI/SCE measurement with 0.04 ΔE*ab repeatability.

10nm Optical Resolution: Covers 400–700nm spectrum for fluorescent material analysis.

2 - Ergonomic Excellence 410g Ultra-Light Build: Compact design for one-handed operation during prolonged use.

2.8” Touchscreen: Intuitive navigation with real-time pass/fail indicators.

3 - Industrial Durability 10-Year LED Lifespan: Withstands 1.2 million+ measurements.

IP54-Rated Housing: Dust/splash-proof for factory floor deployment.

4 - Smart Calibration Auto-Whiteboard Validation: Contact-based calibration with R%≥95% reference tile.

Self-Diagnostics: Error alerts for misalignment or low battery.

5 - Connected Workflow SQCX Software Integration: Generates ISO-compliant reports with SPC statistics.

Bluetooth Printing: Wireless label generation via optional micro-printer.

Product Features

Optical System: D/8 Geometry: SCI (specular included) for paint/coating analysis; SCE (specular excluded) for textiles.

400–700nm Full-Spectrum LED: Eliminates spectral gaps in critical wavelengths.

Measurement Modes: 9 Color Spaces: CIE Lab, HunterLab, and Munsell conversion.

21 Color Formulas: ΔE*00 - CMC(2: 1), and custom tolerance editing.

Connectivity: USB & Bluetooth: Data transfer to PC/mobile devices.

Cloud Sync: Backup measurements to SQCX cloud (optional).

Safety Systems: Overcurrent protection for charging circuits.

Auto-shutdown after 10 minutes of inactivity.

Ergonomics: Adjustable Stand: 0°–90° tilt for horizontal/vertical measurement.

Non-Slip Grip: Textured casing for wet/dry conditions.

Accessories & Options

Standard Kit: 8mm aperture adapter.

SQCX color management software license.

NIST-traceable calibration certificate.

Optional Upgrades: Micro Printer: On-site label generation.

Powder Test Kit: For loose pigment analysis.

UV Cure Module: For fluorescent material testing.

Consumables: 10 × Replacement calibration tiles.

1L Optical cleaning solution (isopropyl-based).

Warranty: 24-month manufacturer’s warranty (extendable to 60 months).

Lifetime technical support via global hotline.

Technical Parameters

Specification Details

Illumination D/8 geometry (diffuse/8°)

Sensors CMOS dual-path array

Wavelength Range 400–700nm (10nm intervals)

Repeatability ΔE*ab ≤0.04 (MAV/SCI)

Inter-Instrument Agreement ΔE*ab ≤0.4 (BCRA II tiles)

Measurement Time 1 second

Battery Life 8 hours (8.000 measurements)

Dimensions 94mm × 68mm × 188mm

Weight 410g (without calibration base)

Operating Conditions 0–40°C, <85% RH (non-condensing
