Cnc Machine - Chinaprice: 2000.00 Dollar US$
Miniature CNC Machine Tools 1 - Main parts are motor box, headstock, slider, machine bed, gear, side cover, connection pieces, tailstock, countershaft, drive belt cover etc.
All of the them are made of metal.
2 - Withe the latest hardware & software design, the intelligent offline CNC system works more stable and much safer.
And handheld operation panel is also available.
3 - Standard G code/PLT file(programmable format) is compatible with the most popular CAD/CAM software, such as Type3, Artcam, UG, Pro/E, MasterCAM, Cimatron and Maintop.
4 - High-precision stepping drive system along with high-precision screw transmission supports the control mode of 2/3-axes Simultaneous Motion
5 - Multi-I/O points control mode: standard I/O signal nodes have 8 input and 4 output signals respectively
6 - Featured with breakpoints memory and appointed file-processing content, 8 different breakpoints information can be saved.
7 - The multi-coordinate systems have memory function, with total 9 working coordinate systems, which allows the user shifts among them and saves the origin information in each coordinate system.
8 - The running frequency/speed of spindle could be adjusted when machining.
9 - The running &machining speed can be adjusted through the button of speed multiplier.
The range of speed multiplier is from 0.01 to 1 with the graduation of 0.1
10 - Under the mode of manual operation mode, system can perform 3 type motions: continuous, step (jog) and distance.
11 - Built-in 512M memory and USB communication port, the machine can directly read files from USB drives and card readers.
12 - Featuring with LCD panel and 24-key buttons, the operation is super easy and fully offline.
13 - Self-detection and fully automatic dynamic upgrade functions are convenient for remote operation and maintenance.
14 - Multi-language display can provide customized demand.
15 - FTP network file transferring function allows files to transfer to the system through the network cable when flash drive damages.
- Posted By: Xian Zhengrui Education Equipment Co.,Ltd
- Phone: +8618792819268
- Address: Room 2902, Block H, Wangzuo Qujiang, Xi'an , Shaanxi , China
- Website: https://zrtech.en.alibaba.com/
Published date: January 4, 2022
- Business Description: Xi’an Zhengrui Education Equipment Co.,Ltd is a professional and comprehensive maker equipment manufucturer integrating R&D, program design, production, sales and service.
