Gearbox Power Loss Right Angle 90 Degree Bevel Gears Drive Miter - China

gearbox power loss right angle gearbox, right

angle 90 degree bevel gears drive, miter

gearbox right angle manufacturers, suppliers

and factory in China.

gearbox right angle features:

1 - Spiral bevel gears drive, right angle

assembly.

2 - Used to transmit rotary motion, mechanical

power and torque.

3 - High efficiency bevel gearbox up to 98%.

4 - Gear reduction ratio 1: 1, 1.5: 1, 2: 1,

2.5: 1, 3: 1, 4: 1, 5: 1, Customized special gear

ratios.

5 - Input power maximum 335 Kw, high torque

maximum 5713 N.

m, input speed and output

speed maximum 1500 Rpm, high speed gearbox

needs, contact Jacton engineers.

6 - Drive input shaft and output shaft

diameter 15 mm, 19 mm, 25 mm, 32 mm, 40 mm,

45 mm, 50 mm, 60 mm, 72 mm, 85 mm, Customized

other shafts diameter.

7 - 42 types drive shaft arrangements and

rotating directions, drive shafts can be

rotated in both forward and reverse direction

with clockwise and counterclockwise rotation

directions.

8 - Soild shaft, hollow shaft and motor flange

adapter are available, customized multiple

spline keys.

9 - horizontal mounting, overhung mounting or

wall mounting are available.

Special

installation, contact Jacton.

10 - (2-way) 2 shaft gearbox, (3-way) 3 shaft

gearbox, (4-way) 4 shaft gearbox are

available.

11 - Low backlash arc minutes, quiet low noise

less than 80dB under 1500rpm at 1 meter

distance, low working temperature less than

50 degree centigrade.

gearbox power loss right angle gearbox,

right angle 90 degree bevel gears drive,

miter gearbox right angleapplication in

printing press, plastic extruder, sewage

auger, bonding equipment, metering auger,

sewage agitator, newspaper conveyor, bottling

equipment, material handling, web finishing,

paper conveying, conveyor, cardboard box

equipment, packaging, satellite dish

antennas, gate valve actuators, food

processing, robotics, rubber processing,

wrapping machine, solar panel, commercial

mower, street sweeper, dual steering,

bulkhead door opener, scissor lift, vertical

pump drive, sand spreader, residential mower,

car wash curtain, snow blower, mining

equipment, crane, agricultural, grain wagon,

harvester, forage harvester, manure spreader,

fertilizer spreader, business form press,

feed screw drive, sewage conveyor, collating

machinery, mixing equipment, conveyor drive,

screw jack system, film processor and pottle

packaging equipment.

Whatever your goal is to

blend, blow, bottle, crank, cut, convey or

the task is to press, propel or raise, Jacton

gearbox is welcomed and ideal power

transmission solution with all these

industries.

Company Contact:

• Posted By: http://www.bevelgearbox.net

• Phone: 8676981585852

• Address: Taibao Business Building, No.1 Langwei Rd,Xinan, C, Dongguan , China

• Email:

• Business Description: Dongguan Jacton Electromechanical Co., Ltd is professional manufacturing

  spiral bevel gearbox, right angle gearbox, 90 degree gearbox, 1 to 1 gear

  ratio gearbox, worm gear screw jack, screw jack lift mechanism, screw

  jack lifting platform manufacturers and suppliers in China.

  Occupied

  5000 square meters, more than 55 employee staffs.

  We consistently

  provides ideal industrial lifting solutions and mechanical power

  transmission solutions with senior engineers, experienced skilled

  workers and practiced sales teams.

  Dongguan Jacton Electromechanical Co., Ltd manufacturing equipments include cnc lathes, gear cutting hobbing machines, radial drilling machines, high speed thread whirling machines, worm shaft grinding machines, vertical milling machines, high precision CNC machine tools, cnc precision automatic lathes, lathes, punching machines, hydraulic straightening machines, polisher machines.

  Testing equimments include noise meters, infrared thermometers, hardness testers, gear meshing testing machines, micrometers, testing lifting screw moving smoothly adjustable working table.

  Dongguan Jacton Electromechanical Co., Ltd spiral bevel gearbox, right angle gearbox, 90 degree gearbox, 1 to 1 gear ratio gearbox, worm gear screw jack, screw jack lift mechanism, screw jack lifting platform customers, distributors, agents, retailers, dealers, traders and branches are distributed throughout the world, such as USA, Canada, Mexico, Brazil, Argentina, Chile, Australia, New Zealand, Japan, Korea, Thailand, India, Indonesia, Malaysia, Philippines, Singapore, Vietnam, Sri Lanka, Pakistan, Iran, UAE, Saudi Arabia, Turkey, South Africa, Egypt, Zambia, Germany, UK, Poland, Sweden, Slovak, Spain, Greece, Italy, Russia, Netherland, Danmark, Belgium.
