Gt Rs328 Resistance Winding Machine Tubular Heater Equipment - China
price: 1.00 Dollar US$
The working theory of GT-RS328 resistance-wire winding machine for the manufacturing of compact spiral coils is to reel the coil to the payoff with a brake gear, guide the resistance wire to precision spinning by the wire carrier, and twine the wire around the core axle by an adjustable speed rotary device.
The inside diameter of the coil is decided by the external diameter of the core axle, which can be altered free and controlled by coder and electronic counter.
The length’s analogue of the resistance wire could be set and amended in the counter to achieve length control.
As long as the wire comes to the preset length, it would be cut through displacement or electromagnet.
The other counter of the machine records and controls the quantities of the spiral coils.
The frequency converter is employed in adjusting the rotational rate of the core axle.
The production capacity is 2500 PCs/8h.
Company Contact:
- Posted By: Zhaoqing City Greater Technology Co., Ltd
- Phone: +8618138589048
- Address: No.4,3rd Floor,Shangmao Cheng,TouCun,DuanzhouQi Road,Duanzhou District,Zhaoqing City, ZHAOQING , GUANGDONG , China
- Email:
- Website: http://heater-machines.com
Published date: March 20, 2025
- Business Description: Zhaoqing City Greater Technology Co., Ltd focus on heater machines and heating element supplies, we offer tubular heater machinery, cartridge heater machinery, hot runner heater machinery, industrial heater machinery, heater supplies, heater raw materials, include tube cutting machines, resistance wire winding machines,welding machines, plug with pin assembling machines, filling machines, feeding machines, reducing machines, trimming machine, anneal machines, bending machines, terminal pins, tube material for heating elements, ceramic beads, resistance wires, MGO rods, terminal pins, flanges etc.
