FM7.5 Self-loading Concrete Cement Mixer

Introduction of FM7.5 Self-loading Concrete Cement Mixer 1 - The blades of FM7.5 Self-loading Concrete Cement Mixer are made of high-strength 16Mn plate, well anti-wear performance, good spiral curve homogeneity, upper leaves with curve and weld reinforcement to increase the life of blades.

2 - High strength steel plate, enhance vehicle load capacity.

3 - Small capacity mixing drum design, the angle is lower than same profession, effectively reduce the gravity of vehicles, improve the driving safety.

4 - Mixing blade with varying pitch design, and simplify the feeding device, ensure the speed faster and mixing performance better.

5 - Widely adopts the automatic welding, weld thickness reduction of nearly 15%, the vehicle with high stability.

6 - Using professional mature chassis, to ensure the vehicle with high-efficiency performance.

7 - Focus on detail, humanized design, fully meet the personalized requirements of customers.

Parameter of FM7.5 Self-loading Concrete Cement Mixer Self-loading concrete cement mixer technical details

Mixing drum Mixer capacity 7.5m3 concrete output/h, mixing speed: 3 gears both positive & inversion turns; maxing slewing angle of the drum: 300 degree.

Engine details Cummings model 4BTA3.9-C110, rated power/turns: 82kw (110HP)/ 2200rpm.

Drive system hydraulic component( variable stroke pump) : Danvers

two grades gear transmission : road/off road, 4 wheel drive Speed low gear speed: 0-9.5km/h, high gear speed : 0-28km/h

Cabin front cabin with rops &fops design

Hydraulic sytem 2 variable stroke pumps provide power separately to car drive and mixer.

2 constant rate pumps provide power to drum slewing, brake, water.

cooling: water/air Joystick all working operation designed in one joystick

Bucket capacity: 0.6m3 hydraulic controlled door

Chute adjustable hydraulic controlled vertical 15 degree movement, horizontal free movement

Water sytem water pump with high pressure washing gun

Climbing angle 30degree with full load

Brake wet brake, parking brake with gear box

Tires off-road engineering tire 16/70-20 PR16

Steering front axle steering, all hydraulic inner steering radius: 1988mm/4130mm outer steering radius: 3767 mm/6030mm

Electric system battery : 2X12V 120Ah, provide lighting and ignition

Fuel tank 110L

Hydraulic oil tank 80L

Carframe all steel welding

Weight off load: 8t, full load : 18t
