Arm Type Platform Vehicle - China

General Specifications

UC-1C underground service vehicles-Arm type platform vehicle is special to worker doing job underground, it's safety and mobility.

Style: UC-1C

All Dimension: Length/width/height7790± 100*1900± 50*2260± 50(mm)

Vehicle Turning Radius: Inner3800(mm)Outer5900(mm )

Empty weight: 8000± 300KG

Rate load: 1000KG

Platform area(mm*mm): 1350± 50*1400± 50(mm)

Max lift height: (6000± 200)mm

Platform Turning angle: 30degree or 2m(left and right)

Underground service vehicles have the same specification as below.

General Specifications

Min.

ground clearance mm ≥ 230

Climbing ability(heavy load) % 25%

Lateral Swing Angle (º ) Both right and left 7~10

Max.

travel speed km/h I gear 4.5± 0.45

II gear 10± 1

III gear 22± 2

Max.

traction kN ≥ 80

Rated loading weight kg 5000± 500

Wheelbase mm 1520

Wheel gauge mm 3410

Turning radius mm R(inner)≤ 4000

R(outer)≤ 6000

Main Configuration

Component Model Manufacturer Note

Diesel engine F6L912W (65 kW) Germany Deutz

Gear-box

(included torque converter) 1201FT20321 US DANA integrated

Drive axle 112 US DANA 2 pcs

Transmission shaft China

Accelerating pedal assembly 208994 US morse

Exhaust purifier 6DZ Canada ECS

Silencer 6DMS Canada ECS

Rim 8.0-20L China

Tire 10.00-20-14 Henan, China

Twin gear pump 2.5PB Italy sailami Standard

PGP511 US park Optional

Liquid filling valve 4517 US Mico

Foot braking valve 4513 US Mico

Hand braking valve 4515 US Mico

Accumulator SBO (0.75L, 3pcs) US HYDAC

Reverser BZZ1-E500C Zhenjiang, China

Rotation Bearing 010.20.400.001.04.11 Xuzhou China

Oil cylinder China

Electrical components Schneider switch, the rest made in

China.



Storage battery 6-Q-110(12 V/110 Ah) China Fengfan 2pcs

Meter box stainless China Tongguan

Frame Normal, half-closed cab an

closed cab China Tongguan
