Simons Cone Crusher Series - China

Application:

Simons Cone Crusher is mainly used in crushing ore, non-ferrous metal, granite, limestone, sandstone and grail.

It is mainly used in metal and nonmetallic ore , cement , construction , metallurgy industries etc .

Working Principles:

When it is on operation , the eccentric bushing spins by the electronic motor through triangle belt , belt wheel , transmission shaft, bevel pinion and bevel gear.

The axial lead swings forcing by the eccentric sleeve , making the surface be close or far away to the mortal wall untimely.

Because of this , the materials are impacted and squeezed bended continuously to be crushed .

After times of this , the demanding materials are discharged .

Characteristics :

1 - Comparing to the traditional cone crusher , it possesses the higher property and production capability .

2 - Adopting the lamination crushing principle, the percentage of cubic products can be above 90% with uniform granularity .

3 - The crushing cavity structure is designed by the lamination principle , increasing the crushing ratio and production .

And the percentage of the cubic products is to be above 90%.

4 - When the non-crushing materials enter into the equipment , they are released automatically by the protector .

Then all the discharging mouth can be recovered .

5 - Adopting the imported long diameter principle axis, heavy mainframe and automatic control system , the equipment is sturdy and durable and the operation is steady and reliable.

6 - Adopting the automatic clear –cavity technology , low cost and extensive scope of crushing .

It can not only crush fixedly but also movably.

Technical Parameters

Model Dynamic cone

diameter (mm) Type of

cavity Feed size

(mm) Adjustable

discharge

size(mm) Production Rotate

speed

(r/min) Power Weight Overall size

(L*W*H)

(mm)

2ft 600(２＇ Fine 72 6-38 16-54 575 22 6 2195*1158*1651

Coarse 109 9-38 18-68

Worse 109 13-28 23-72

3ft ９００( 3＇) Fine 102 9-22 45*91 580 75 15 2656*1746*2241

Coarse 175 13-38 59-165

Worse 178 25-38 118-163

4ft 1200(4＇) Fine 131 9-31 63-188 485 110 20 2656*1974*3112

middle 156 13-38 100-200

coarse 191 19-51 141-308

Worse 250 25-51 190-317

41/4ft 1295(41/4＇) Fine 137 13-31 109-181 485 160 27 2809*2354*3156

middle 210 16-38 132-253

coarse 241 19-51 172-349

Worse 259 25-51 236-358

51/4ft 1676{51/2＇) Fine 209 16-38 181-327 485 220 55 3911*2870*3771

middle 241 22-51 258-417

coarse 269 25-64 299-635

Worse 368 38-64 431-630

7ft 2134(7＇) Fine 278 19-38 381-726 435 315 110 4613*3251*4732

middle 334 25-51 608-998

coarse 369 31-64 789-1270

Worse 460 38-64 880-1361
