High Quality Lpms 10a 08 Super Miniature Slip Ring With 8 Circuits - China

Description:

This unit can be used in any electromechanical system that requires

unrestrained, continuous rotation while transferring power or data from

a stationary to a rotating structure.

It is also called a rotary electrical interface, commutator, collector, swivel

or an electrical rotary joint.

It can improve electromechanical capability,

simplify system design, eliminate possible damage while rotation.

It’s

the key apparatus of various precision rotary worktable, electric test

instrument, manufacture and process control instrument.

The LPMS- 10A- 08 super miniature slip ring is a standard, off- the- shelf

unit that uses gold contacts at the rotary interface.

Color- coded lead

wires are used on both the stator and rotor for simplifying electrical

connections.

The LPMS- 10A- 08 allows tremendous flexibility in dealing with system

size restrictions.

It is available in 1 to 8 circuit configurations.

Features:

â—† 8 circuits models

â—† 1 amp per circuit, 240 VAC/ DC

â—† Precision assembly to provide exceptional rotational life

â—† Speed up to 300 rpm continuous

â—† Gold to Gold contacts

â—† Flexible, color- coded, silver- plated lead wires

â—† Superior handling of low level control signals

â—† Metal housing optional

Advantage:

â—† Low torque minimizes system torque budget

â—† Compact design to fit in the most demanding space.

â—† Compact package

â—† Low electrical noise

â—† Quick shipment per your urgent requirement

◆ 360°continuous rotation

â—† Addition of special components

Main Application:

â—† Electrical test equipment

â—† Manufacturing and process control equipment

â—† Indexing tables.

â—† CCTV pan / tilt camera mounts

â—† Robotics, rotary sensors, urgent illumination equipment

â—† Exhibit / display equipment.

â—† Mini- type wire- rolling machine

â—† Closed- circuit control

Specifications

Operating Speed 0- 300 rpm

Number of Circuits 8

Voltage 240 VAC/ DC

Current Rating 1 amp per circuit

Temperature Range - 20℃ to +60℃

Contact Material Gold to Gold

Lead Size 30# silver plated copper

Lead Length Standard 250 mm ( 9.843inch)

Dielectric Strength ≥500 VAC @ 50Hz, between each

circuit

Insulation Resistance 1000 MΩ @ 500 VDC

Electrical Noise 1mΩ Min

Housing Material Stainless steel
