Chinese Cnc Turning Lathe Ck6136a - China
price: contact company for price
Chinese Cnc Turning Lathe CK6136A is widely used CNC machine tools for metal cutting, turning or drilling with rotating action.
HAISHU brand CK series horizontal CNC lathes provide an affordable, entry-level lathe with exceptional flexibility.
Our CNC Lathe is equipped high precision, high speed spindle, ultrasonic frequency quenched guide ways, fast cam clamping device and servo motor drive which offer high quality, stability, rigidity and accuracy for a variety of metal processing applications.
Chinese Cnc Turning Lathe CK6136A Specification: Item
Unit Technical parameters
CK6136A
Max.
rotation diameter over bed
mm
φ360
Max.
rotation diameter over pallet
mm
φ245
Max.
workpiece length
mm 750/1000
Main transmission form Independent spindle
Spindle speed mode Frequency stepless speed
Spindle speed range r/min
200~2500
Spindle head form 6-A2
Spindle bore
mm
φ60
Spindle hole outside taper MT6
Chuck diameter
mm φ200
Main motor power
kw 5.5
Turret maximum stroke
mm X: 260 Z: 760/1020
Fast-moving feed
mm/min X: 6000 Z: 8000
Repeat positioning accuracy
mm X: 0.01 Z: 0.015
Workpiece accuracy IT6-IT7
Workpiece surface roughness Ra1.6
Dia.
of tailstock quill
mm φ60
Tailstock quill stroke
mm 120
Taper of tailstock quill MT4 Section of turning tool
mm 20×20
Size(L×W×H)
mm
2170/2420×1540×1650
Net weight
kg 1800/2000
Company Contact:
- Posted By: Taian Haishu Machinery CO.,LTD
- Phone: +8613562857553
- Address: Shankou town, Taian , Shandong , China
- Email:
- Website: https://www.wheelcncmachine.com
Published date: July 7, 2018
- Business Description: Taian Haishu Machinery CO., LTD was found ed in 2001, mainly produce cnc lathe, cn c machine centers, all through CE.
