Cnc Wheel Polishing Repair Lathe Machine Ck6187w - China

Quick Details

Condition:

New

Type:

Horizontal

CNC or Not:

CNC

Automatic Grade:

Automatic

Max.

Swing Diameter:

870mm

Place of Origin:

Shandong, China (Mainland)

Brand Name:

HAISHU

Model Number:

CK6187W

Voltage:

380v

Power(W):

11kw

Dimension(L*W*H):

2680X1820X2050(mm)

Weight:

3600KG

Certification:

ISO9001: 2008, CE

After-sales Service Provided:

Engineers available to service machinery overseas

Name:

CNC Wheel Polishing Repair Lathe Machine CK6187W

Machine Type:

Lathe Machine CNC

Color:

White

Function:

Rim Surface Repair

Product type:

Alloy Wheel Refurbishment

Warranty:

12 Months

Precision:

High Precision Machine

Spindle bore:

82mm

Spindle speed:

150-2500rpm

Control system:

SYNTEC or touch screen

Product Application

CNC Wheel Polishing Repair Lathe Machine CK6187W provides you best CNC machine solutions for alloy automobile wheel machining, super finishing and maintenance, it has the characteristics of high quality, high precision and high efficiency.

The CNC wheel machine, wheel repair machine and brake drum lathe are widely used in automobile wheel factories and some repair shops.

Our partners are those famous brand from European countries, United state, South Korea, Russia and Asia etc.

Max.

turning diameter over the bed

34”(φ870mm)

Machining diameter of the wheel

30 inch

cnc system

SYNTEC or Touch screen

detection mode

touch probe or laser

Main motor power

11kw

Fast-moving feed

X - axis: 5000mm/min Z - axis: 8000mm/min

Repeat positioning accuracy

X - axis: 0.01mm Z - axis: 0.015mm

Standard tool mode

4 station electric turret

Section of turning tool(mm)

25*-25

weight 3200kq

CNC Wheel Polishing Repair Lathe Machine CK6187W Main Operation Features

1 - Achieve the wheel surface profile measurement and data collection and Program Optimization, 2 - Automatic precision repair and machining in accordance with the curve of the wheel surface

3 - Spindle frequency stepless speed;

4 - X / Z axis servo drive;

5 - Manual jaw self-centering chuck;

6 - Machine guard full protection;

7 - Automatic oil lubrication.
