Non Welded Bow Spring Casing Centralizer - China

Non-welded bow spring casing centralizer casing centralizer is applied

to centralize casing in wellbore, and improve cementing quality

1 - API 10D standard

2 - The attached shapes are pressed by moulding instead of welding and rivet.

3 - Removable and easy to use and transportation .

4 - Starting and restoring force meets API 10D standards.

5 - Alternative turbulence plates can enhance displacement efficiency effectively.

Specifications

Specifications 20' 18' 16' 14' 13' 12¾' 10¾' 9' 7' 7' 6' 5½' 5' 4½'

Casing Size 20' 18' 16' 14' 13' 12¾' 10¾' 9' 7' 7' 6' 5½' 5' 4½'

Open Hole Size 24'

26' 22'

24' 20'

22' 18' 17½' 17½' 12¼' 12¼' 9' 8½' 8½' 8 ½' 6 1/2' 6'

Max O.D. , mm 650

714 590

680 550

613 484 470 466 370 375 273 252 245 256 190 181

Non Welded Bow Spring Casing Centralizer
