Pcb Production Printed Circuit Board Chemical Etching Machine - China
price: 13000.00 Dollar US$
Dimension:
7820mm×2300mm×2000mm
Working height:
900mm±25mm
Working width:
650mm
Wheel base:
28mm 35mm 48mm 70mm
Working speed:
2m/mm(preset working speed)
Supply voltage:
Three phase four wire, 380V/50Hz
Total power:
41KW
Max work piece:
610mm×460mm
Min work piece:
150mm×150mm
Working thickness:
0.1-3.2mm
Water consumption:
8~12 L/min
Working temperature
0 - 55°C
Highest Temperature
70°C
Company Contact:
- Posted By: Everest PCB Equipment Co.,Ltd
- Phone: +861065485421
- Address: Building 10, No.A8, Hujiafa Road, Tongzhou district, Beijing , Beijing , China
- Email:
- Website: https://www.pcbmachine.com
Published date: March 18, 2020
- Business Description: Everest has two equipment manufacturing factories, one is professional horizontal equipment manufacturing factory, one is professional electroplating equipment manufacturing factory.
Everest has more than 30 years experience in PCB industry.
The products using the latest technology, to achieve good cost-effective equipment.
When manufacturing equipment, Everest follows a separate design for each equipment, a separate standard for each equipment, and designs the equipment according to the customers environment and humanities, avoid defects from the beginning of the design, these elements will be taken into consideration to achieve the best use of the equipment, so as to achieve the intended work objectives and solve the problems in production.
