Ram Type Cnc Sinker Edm Machine 540 75a - China

Specifications of CNC Sinker EDM Machine

Model: CNC-540 / 75A

The movement of Axes

1 - Longitudinal travel of worktable X -axis 500 mm

2 - Cross travel of worktable Y-axis 400 mm

3 - Ram servo travel Z-axis 310 mm

Worktable

1 - Maximum Load 2000 kg

2 - Out size of work tank : 1370*720*450 mm

3 - Dimension of worktable 850*450mm

Oil Tank

1 - Gross weight of oil tank 350 kg

2 - Capacity of oil tank 2000 Litres

Other Parameters

1 - Maximum distance from the work head to the surface of worktable 390~690 mm

2 - Maximum weight of electrode 150 kg

3 - Gross weight of complete machine 2500 kg

CNC control unit

Control Method and Axes .

Close Loop(xyz 3-axis)

Min.

Setting Unit .

0.005mm(0.00 1mm)

Max.

Setting Unit .

9999.995mm(99 99.9999mm)

Coordinate System .

INC/ABS

Display System .

15 inch CRT/VGA

Control System .

PC BASE

Inching .

0.005mm(unit)×1， ×5，×10

Data savings.

10000 groups

Max.

Machining Current.

.

75A

Total Power input 6KVA

Max.

Material Removal Rate .

560 Mm /min

Electrode Wear Rate <0.2 %

Best Surface Roughness .

0.15 um Ra

External Dimension(X.Y.Z) .

830×840×1850mm

Packing Dimension(X.Y.Z) .

930×940×2050 mm

Net Weight .

370 kg

Machining Setting amount Per set .

30

Steps 10

Machining Mode.

Sqr/X/Rd/Crs/Side Sparking

orbit Cutting .

XY(Z Lock), XYZ

Continuous Machiningmakehole amount .

100

Standard Accessories:

1 - Monitor Displayed&3-AXes Linear Scales

2 - Z Axis DC Servo Motors & Ball scr3ws.

3.1 PCS Electorde Holder.

4.1 PCS Working Lamp.

5.1 Set Tools With Toolbox &Clamping Kits.

6.1 Set Cartridge Paper Filters.

7 - Machine Level Mounts.

8 - Auto Fired Detect System&Extinguisher.

9 - Remote Control box.

10 - Operation Manual&Technical Data.
