Wrap Around Sticker Labeling Machine - India

We are reputed manufacture of Sticker

Labeling Machine for Round Bottle -NKSAL

120 - This Sticker Labeling machine can

perform wide range of wrapping like wrap

around , Partial wrap on round surface.

Salient features:

Sticker Labeling machine offer following

outstanding basic features:

cGMP model

High Production Speed up to 120 BPM

depends upon the type of diameter of Round

container.

S.S. 304 Constructions.



Accurate label dispensing due to use of

either servo motor or efficent stepper

motor inconjuction with mirco stepping

driver.

Secondary Pressing unit.

Facility to incorporate the Batch coding

printing like Inkjet printing or hot foil

coding & contact coding.

Automatic Label Length Detection.

No change part required for label and

bottle.

Basic Machine configuration:

Imported Gear Motor and gear box

A.C. Frequency Drive for main drive.

Imported Servo motor with driver or

stepper motor with driver

Imported Sensor for Label & Container

PLC system with touch screen HMI.

Technical specification:

Speed

Up to 120 Vials / min.

Electrical Supply

1 HP

Power Requirement

230 Volts, Single Phase, 50 Hz

Height of Conveyor

Adjustable from 800 to 850 mm

Dimension

1500 mm (L) x 1000 mm (W) x 1250 mm (H)

Weight

300 Kgs (Approx.

)

Gross Weight

500 Kgs (Approx.

)

Optional features available on demand

like:

Following features are avilable on

customer demand in our all range of

sticker Labeling machine.

Automatic rejection system with separate

conveyor.

Missing Label Detection on Product

Toughened Glass Safety Cabinet

Empty Roll Alarm System

Vision system for Checking Labels

Tower Light Showing Machine Status
