Supply Casting Valves - China

price: 10.00 Dollar US$

Supply Casting Valves

Products Photos Catalog Casting Valves Photos Catalog

Type: Butterfly, Gate, Check, Global, Y strainer

Size: DN40-1200 or 1.5-48' or above

Working Pressure: PN10/16/20/25, 150LB-2500LB

Suitable temperature: -45c~150c Standard:

(1)Design and manufacture: DIN3352, BS5163, BS5150, ANSI B16.34, API600, API6D, API609, EN593, GB, T12238 (2)End connection: ANSI B 16.1, ASME B16.5, B16.47, B16.25, B16.34, JISB2212-JISB2214, DIN2543-2550, EN1092, AS2129, ISO 5211

(3)Wall thickness: API600, BS1868

(4)Face to face (end to end): EN 558, ASME B16.10, DIN3202, ISO5752, JIS, API609, MSS, BS5155

(5)Inspection and test: API598, EN12266-1, BS6755, API6D, ISO5208

Materialfor main parts:

(1)Body: CI, DI, WCB, ALB, CF8, CF8M

(2)Disc: DI, ALB, C95400, Rubber lined Disc, 1.2501, 1.4529, CF8M, CF8, Hastelloy

(3)Stem: SS416, SS410, SS304, SS431

(4)Seat: NR, Hypalon, EPDM, Neoprene, NBR, Wear-Resistant EPDM, Viton, Silicon, Heat-Resistant EPDM, WhiteNBR, WhiteEPDM, EPDM(NSF), PTFE

Coating: Fusion bonded epoxy coated

Connection type: Flanged type, Push-on type, Mechanical Joint type, Plain ends type

Sealing: Soft sealing or metal-to-metal seat, Flexible graphite Operation: Manual, Pheunatic, Electric, Hydraulic and Pnewmatic-Hydraul

Appropriate medium: Air, water, sewage, steam, coal gas, oil

Packaging: Export polywood cases, or as per customers' requirements

Min Order Quantity: According to customer's requirement

Delivery Time: 30 days after order conformed

Payment: By T/T or L/C

Application: Fresh water, sewage, sea water, air, vapor, food, medicine, oils.

acids, alkalis, salt etc.


Company Contact:


  • Phone: 8653255570858

  • Address: Lian Yun Gang Road, Qingdao, China, qingdao , China

  • Email: Email


Published date: July 16, 2017

  • Business Description: HQ Pipeline co., ltd, is a professional manufacturer & exporter of all

    kinds of pipe fittings and valves in China: Forged Steel Pipe Fittings,

    Flanges, Butt Weld Pipe Fittings, Nipples and Coupling, UL/FM Ductile

    Iron Grooved Pipe Fittings, Gate Valve, Butterfly Valve, Check Valve,

    Strainers, Ball Valve.

    and OEM/ODM service, which are widely used in

    the field of petroleum, natural gas, ship building, metallurgy, electric

    power, chemical industries, fire protection etc.
