Wpl Right Angle Gearbox High Precision Planetary Speed Reducer - China

1 - Quick Details

Place of Origin: Jiangsu, China ( Mainland)

Brand Name: MINGDI

Model Number: PL / WPL series

Gearing Arrangement: Planetary, Planetary or Helical bevel

Output Torque: 800N.

m

Rated Power: 5W- 1500W

Input Speed: 1500, 2000 & 3000 r/ min

Output Speed: 1.3~193rpm

Transmission Ratio: 3- 10000

Fault output torque: two times of rated output torque

Noise: less than 62db

Backlash: 6- 8Arc- mim for one stage, 8- 10 for two stage, 12- 15 for three stage

Weight ( kg) : 2.1- 440kg

Certificate: CE, ROHS, ISO9000

IP Grade: IP65

Average spanlife: 20000H

Warranty: 18 Months

2 - Product Characteristics

A.

Low backlash can reach to <3'

B.

Helical gear enable more smooth transmission and lower noise

C.

Low noise can reach to 60 dB( A)

D.

longer life reach to 30000h from our high- quality key components

E.

Comprehensive models to fit your different applications

3 - Product Brief Introduction & Picture Show

High precision planetary gearbox adopts helical gear design.

Its mesh betweem gears is much more convenient than previous spur gear.

Noise is reduced, backlash is small( <3”) , especially show excellent performance of high precision servo motor when low ripple rotate, no need for maintenance and easy assembly.

There”re many ratios for your selection( 3, 4, 5, 6, 7, 8, 9, 10 for one stage) .

We can get more ratios with different mix.

Company Contact:

• Posted By: Changzhou Mingdi Machinery Co., Ltd

• Phone: 8651985522706

• Address: No. 32 Changsheng Road, Wujin District, Changzhou , China

• Email:

• Website: http://www.czmdjx.cn/

• Business Description: We are a professional transmission machinery manufacturer of producing gears and gearbox, With indepentent import and export rights.

  Our company has complete equipments and solid technical force, the products have the features of steady transmission and low noise, the main products are various gears, gearbox and reducers, which are widely used in pour fields of electrical machinery, plastic extrusion machinery, railway engineering machinery and metallurgical machinery, meanwhile, custom orders for non standard reducers and gear are welcomed, looking forword to your kind inquires.
