Tl 780 Fully Automatic Gold Hot Foil Stamping Machine For Paper - China

TL 780 Fully Automatic Gold Hot Foil Stamping Machine For Paper 1 - The Auto Hot Gold Foil Stamping Machine For Paper Box is designed for the Hot Foil Printing, Hot Foil Stamping, Die Cutting, Embossing Convex and Creasing etc technologies, its suitable for paper, cardboard, plastic sheet and so on.

It can finish feeding, Hot Foil Printing, collecting work cycle automatically.

2 - The Auto Hot Gold Foil Stamping Machine For Paper Box is composed of four parts: main motor, Hot Foil Printing, auto feeder and electric equipment.

The motor's main transmission is by bend shaft structure driving the platen running up and down, plus the pressure adjusting structure, coordinate to finish Hot Foil Printing or die cutting job.

3 - The electrical parts are composed of main motor control, feeder/collect control and foil feeder control and so on.

The whole machine is controlled by micro processor.

4 - The Auto Hot Gold Foil Stamping Machine For Paper Box Control is equipped with the automatic lubrication system.

MACHINE SPECIFICATIONS

Model

TL 780 Automatic Hot Foil Stamping Machine

Max.

sheet size

780*560 mm

Min.

sheet size

280*220 mm

Max.

feeding pile height

800 mm

Max.

delivery pile height

160 mm

Max.

working pressure

110 T

Main motor power

12 kw

Air pump displacement

40 m³ / h

Paper range

100 - 2000 GSM

Max.

mechanical speed

1500 S/H Paper less than 150 GSM

2500 S/H Paper More than 150 GSM

Machine noise

Less than 81 db

Electric plate power

8 kw

Overall machine dimensions

3700*1910*2200 mm
