Yd2600 Rc Hybrid Uv Printer Advertising Billboard Printing Machine - China

YD2600-RC Hybrid UV Printer adopts imported original grey level Ricoh G5 internal heating industrial printhead, the number of printhead can be increased or decreased according to your requirements, the print speed can up to 36㎡/h (4 PASS), can meet the demands of large quantities production capacity.

YD2600-RC is a high-speed and high - precision UV printer for medium and small size processing enterprises and can meet their high precision and high speed production requirements.

Printer model YD2600-RC

Print head Ricoh-Gen5

Number of nozzles 3-8 pcs

Print resolution 600*2400dpi

Print width 2.6 m

Print materials Rigid and Flexible materials

Print thickness 50 mm

Ink type Eco UV curing ink(No VOC)

Print speed

4pass single row36 ㎡/h；double row 72㎡/h

6pass single row27 ㎡/h；double row 54㎡/h

8pass single row20㎡/h；double row 40㎡/h

Ink color C, M, Y, K, Lc, Lm(optional)

Special ink UV White ink

Input format

Adobe Postscript Level 3, PDF, JPEG, TIFF, EPS, AI

Printer weight 1400KG

Printer dimensions 5.2m[L] × 1.7m[W] x 1.6m [H]

Power 8.5 KW (38A)

Working environment Separate, little sunlight, ventilated workshop Temperature: 18℃～30℃ (64℉～86℉) Humidity: 30%～70% (Non-condensing) Ventilation equipment : Suggest Overhead exhaust fan, displacement 600 cfm

1 - About the price and quality?

We can not say we are the best supplier, but we are honesty for our quality and price.

Good quality is our first rule, and good service is our mission.

We produce machines as 5S management rules, and ISO standard.

2 - Why do you choose our factory?

We produce flatbed printing machine, digital flatbed printer is a new product in printing industry, it can

print on the surface for various kinds of flat objects directly, such as crystal, leather, glass, metal, ceramic

tile, PVC, PP, PE and so on.

Any pictures can be printed on the surface of the subjects by the printer with

high resolution, it is the fastest flatbed printer on the current market.

And we will keep you with a best

service, give us a chance, also give your a chance to know this field if you really want to know this printer.

3 - What is the printer operation?

a.

Through a digital camera or scanner to get File sources of pictures.

b.

Through the computer images to typesetting modified document layout.

c.

Through the universal printer output files to print.

d.

Print objects requirements.

Company Contact:

• Posted By: Shenzhen Yueda Printing Technology Co.,Ltd.

• Phone: 13925227012

• Address: Gangbei Industrial Park,Baohe Road,Longgang District,Shenzhen, shenzhen , China

• Email:

• Website: http://www.yo-da.com

• Business Description: Yueda specializes in manufacturing UV flatbed printer for over 8 years.

  Our printing machine can print any picture on any flat materials with embossment and 3D effect.
