China High Quality Hot Sale Full Automatic Servo Card Sorting Puching Machine Supplier - China

Patent NO.

：ZL200820093676 - x


Product Model：KS-CPM-S025

Product Category：Smart Card Equipment

Dimension：(L)1700mm X (W)2500mm X(H)1800mm

Weight：1200Kg

Specifications：

Power：7.5KW

Power Source：AC380V/50Hz

Air Pressure：0.6 Mpa

Punching Accuracy：±0.1mm.

Punching Material：PVC, ABS, PET or mixed material

Material Size：length size：400mm -480mm width size：282mm-452mm

Capacity：300~500 sheets/hour

Features

1 - Feeding unit: Auto feeding, applying the lift chain system and sensors checking, it could ensure every sheet feeding even and stably.

2 - Position Unit: applying high sensitive sensors to make the position very accurately.

3 - Transfer unit: Applying the high accuracy guide screw to make the materail running stably and accurately.

4 - Punching unit：Using the PLC to control the punching system to make the punching stably and low noise.

The punching accuracy reaches ±0.1mm.

And it also could work well with lamination deform card to reduce the NG rate.

5 - Sorting Unit: the machine could place the same position cards into the same output box, it could save the manpower to sort the cards.

6 - Output Unit: the output boxes could be designed from 1 box to 64 boxes depends on the client's request.

It could solve the sorting problem with mixed cards.

7 - Control Unit: applying the touch screen to control, it is easy and fast to operate.

8 - Applying the big power servo punching system to make sure the puching stably, low noise, fast.

The punching speed is adjustable to adapt to different thickness sheet material.

Applying Area:

This machine is used for punching ISO standard cards or NON-ISO standard cards.

It applies the sorting function to save manpower cost.
