Cnc Machining Center - China

4-axis cnc machining center is used for milling, drilling and cutting aluminum profiles and light alloys.

Specially designed for the manufacture of various aluminum and PVC profiles.

PRODUCT DESCRIPTION 4-Axis CNC Machining Center Product Description

Using advanced industrial CNC systems, friendly machine interface and operation is simple Suitable for aluminum, aluminum / wood composite profile, profiles and other light alloys of copper, as well as the u-PVC profile processing Within a range of 90 ° ~0 ° ~-90 ° 4-axis machining In one clamping profiles complete milling, drilling, chamfering, grooving and other multi-functional precision machining Made of high strength welding structure, after heat aging after annealing processing guarantee high rigidity and high stability Adopts imported high precision linear guideways, ball screws, gear racks and servo motor, ensuring smooth motion, positioning and processing of high precision High-quality imported automatic tool change for high speed motorized spindle ensure stability, stability of rotation noise, cutting ability Magazine is equipped with 6-station capacity, adjustable pneumatic special fixture to ensure efficient processing Double table for two, or two kinds of profile machining, interactive feeding, non interference Multiple safety protection structure to ensure operator safety 4-Axis CNC Machining Center Industry Application

Transportation products manufacturing (trains, cars, ships, etc), Medical equipment, bathroom accessories, windows&doors, curtain walls, interior decoration and other industries.

4-Axis CNC Machining Center Technical Parameters X-axis stroke 7000mm Y-axis stroke 500mm(3 axis)

380mm(4 axis)

X-axis feed rate 0~55m/min Y-axis feed rate 0~50m/min

X-axis positioning accuracy ±0.15mm Y-axis positioning accuracy ±0.02mm

Z-axis stroke 300mm Repeat location accuracy ±0.02mm

Z-axis feed rate 0~25m/min

Roughness Ra 6.3 um

Z-axis positioning accuracy ±0.02mm A-axis travel ±95°

A-axis feed rate 10r/min A-axis positioning accuracy ±1’

Spindle Power 7.5kW Spindle Speed 0~24000rpm

Power Specification 380V/50Hz Total Power of Machine 12.5kW

Working Pressure 0.6～0.8MPa Machine Size 11300×2350×2550mm
