Medium Speed Wire Cutting Machine - China

Medium Speed Wire-Cutting Machine

Machine tool type PD-50SE/ST PD-63SE/ST

Worktable Size (W*L) 1000×750mm 1170×830mm

Max trip of X, Y-axis of the worktable (Y×X) 630×500mm 800×630mm

Max cutting thickness 300mm 300mm

Max load weight of Economical Linear Cutting Machine Tool 800kg 1000kg

Max cutting efficiency 180mm²/min

Max processing current 7A

Optimum surface roughness First cutting Ra≤2.3um, second cutting Ra≤1.6um, third cutting Ra≤1.0um

Cutting accuracy Line≤±0.0025mm, taper≤±0.01mm

Hop accuracy 0.01mm/0-200mm, 0.015mm/0-350mm, 0.02mm/0-500mm

Max cutting taper of Medium-Speed Linear Cutting Machine Tool ±3°/80mm

Electrode wire diameter range (molybdenum wire) 0.12-0.25mm(standard configuration 0.18mm)

Driving mode X, Y, U, V-axis servo (Panasonic servo) or stepper ( 5-phase 10-pat), Z-axis electric silent elevation

Cutting fluid box configuration High pressure slow wire filtration, volume 100L

Cutting fluid ratio Dick liquid mixed with pure water, concentration 8-12

Power consumption of complete machine ＜2KW

Power supply Three-phase four-wire 380VAC/50HZ

Host weight 2750kg 3450kg

Host outline size (L*W*H) 1850×1400×1800mm 2070×1655×2060mm

Packaging outline size (L*W*H) 2050×1600×1900mm 2340×2100×2160mm
