Tobee® 12 10f M Slurry Pump - China

Tobee 12/10F-M Slurry Pump is a proven horizontal end suction centrifugal slurry pump that will reliably and economically handle abrasive and corrosive medium duty services, The 12/10F-M medium slurry pumps are of heavy-duty construction, designed for continuous pumping of highly abrasive and corrosive slurries.

They feature a wide choice of replaceable abrasion resistant metal casting liners and Impellers, which are all interchangeable within a common casting assembly.

Design Features: √ Wear is reduced and maintenance simplified by the use of a one-piece volute liner with no radial split at the cutwater

√ Front and back liners are adjustable while the pump is running to maintain efficiency and minimize wear; also reduces expeller clearance maintaining shaft seal performance

√ Internal liners can be fully worn as the cast iron split outer casing provides structural integrity and high operating pressure capability

√ Safe closed valve operation is assured by the pressure relief device fitted as standard on all models

√ An easily removable hardened steel or ceramic coated steel shaft sleeve with o-ring seals at both ends protects the shaft from abrasive or corrosive contaminants

√ Reduced and simplified inventory is assured with a minimum number of wearing parts

√ Reduced seal pressure and internal recirculation is achieved by the pressure molded deep sealing vanes on the front and back of the impellers

√ Extended bearing life is assisted by large diameter flingers and static seals to prevent ingress of liquids while operating and while stopped

√ Grease relief holes prevent bearing overheating due to over greasing

√ The best material for each application can be chosen from the wide range of erosion and corrosion resistant materials, enabling wear life optimization of each component

Company Contact:

• Posted By: HEBEI TOBEE PUMP CO., LIMITED

• Phone: 15633815619

• Address: No. 266, Tianshan St, High-tech Zone, Shijiazhuang City 050000, Hebei , China

• Email:

• Website: https://www.slurrypumpsupply.com/

• Business Description: Capacity

  Tobee® Pump has a wealth of experience in the manufacturing and service of pumps and accessories; in fact Tobee® Pump has machinery manufacturing experience of over 45 years having achieved great success with R&D and manufacturing of Pumps for more than 30 years.

  The annual production capacity of pumps in our factory surpasses 10,000 easily.

  Tobee® Pump has a tremendous market share that covers more than 120 cities in China including many provinces and autonomous regions and more than 80 countries.
