Air Made In China Low Pressure Electric Scroll Dive Compressor - China

Type: Screw

Configuration: Stationa ry

Power Source: AC Power

Lubrication Style: Lubricated

Mute: No

Place of Origin: Guangdong, China (Mainland)

Brand Name: AirHorse

Model Number: AHB-10A

Voltage: 380V/3PH/50HZ or customized

Dimension(L*W*H): 860*7 40*960 mm

Weight: 240KG

Certification: ISO, CE, ASME, CCC etc.

Warranty: 1 year for whole machine, 3 years for air end

After-sales Service Provided: Engineers available to service machinery overseas

Free air deliver: 1.1m3/min

Discharge pressure: 8bar or 0.8MPa

Motor power: 7.5KW/10HP

Compression stage: Single stage

Cooling model: Air cooling

Drive method: Belt driven

Air outlet pipe diameter: 3/4''

Noise level: 62-66dB

Screw type: double screw

Packaging & Delivery

Packaging Details: Wooden crate pallet + foam board + bubble film, or Full closed wooden case.

1pcs/package.

Delivery Detail: Shipped in 25 days after payment Features Of Belt Driven Screw Air Compressor 1 .

Air end with high-efficiency.

2 - Double screw air end with low noise, super silenced enclosure.

3 - Elegant compact design.

Fully open access door to inner parts for easy service.

4 - 100% continuous duty operation.

Load/No Load operation automatically.

5 - High quality CE Certificate industrial electric motors.

ISO, CE, UL Certificate approved.

6 - Easy to use and read LCD control panel with chinese, english, russian, spanish etc.

language optional.

7 - High temperature, high pressure and anti-rotation shutdown automatically.

8 - Energy efficient operation, more environmentally.

9 - 5 micron, water-resistant air filtration material

10 - 1 year full machine warranty, 3 years air end warranty.

11 - Supply the machine with different working voltage according to customer's request, such as: 380Volt, 3phase, 50hz

415Volt, 3phase, 50hz

380Volt, 3phase, 60hz

220Volt, 3phase, 60hz etc.
