C10 - C21 double layer roll forming machine analysis

C10 - C21 double layer roll forming machine is produced

by rolling technology is a kind of equipment, it is a press

sheet steel cold roll forming machine, including the frame,

the bottom of the top roller, roller and guide rail, the

bottom roller, guide rail and can move on the frame of top

roller is installed on the frame, guide rails can be on the

guide rails are installed on mobile positioning block,

positioning blocks and set in the front baffle on the roller

end connection.

One end of the top roll and bottom roll the

roller locking device.

Top roller is equipped with top roll

adjusting bolt and nut pressure on.

When used, the rising of

the top roll through the locating piece adjust the position

of the baffle to need before the processed steel plates

placed in between the two rollers, adjust the compression

nut, the preliminary pressed to the required shape steel

plate, and locking roller locking devices, to start the

equipment can produce.

And when C10 - C21 double layer roll forming machine

changing the mold, the rising of the top roll mould set on

the roll, then put the roll down, adjust the two roller

spacing to need appropriate distance, locking roller locking

devices.

The utility model has reasonable design, simple

structure, easy manufacturing, mold the characteristics of

easy to change.

It is applied to sheet material processing

molding equipment, can realize the edge and transverse

shear, cut, and other functions.

And it is a kind of

material saving, energy saving, efficient metal sheet

forming new technology and new technology equipment.

Make

use of this equipment, not only can produce high quality

steel products, but also can shorten product development

cycle, improve production efficiency, so as to improve the

market competitiveness of enterprises.
