Semi-Automatic Tube Bending Machine

Tube Bending Machine

Model: SB-38NC

Max.

Bending Capacity: ￠38.1 (1.5”)×2mm

Bending Degree: 0-190°

Bending Radius: 20-200mm (for machine)

Min Bending Radius: R≥1.5D (for pipe)

Mandrel Length: 2000mm(can be customized)

Max.

Bending Speed: 90°/s

Bending Accuracy: ±0.1°

Motor Power: 4 Kw

SLS Semi-automatic tube bending machine has an NC control unit to allow the operator to program the bend degree (C axis)-the standard memory can store up to 16 programs each with 16 sequential bends.

This allows the operator to select from the memory to bend sequence they require and load the tube and start bending.

The rotating and feeding (B&Y axis) are controlled manually.

Other movements as die working, mandrel working are controlled by hydraulic.

Pipe Bending Machine combines easy-to-use operation with high bending accuracy and cost effectiveness.

It is the practical semi-automatic solution for small to medium productions.

STANDARD

Bending Axis-by Hydraulic, Feeding Axis-by Manual, Rotating Axis-by Manual.

Human Interface offers easy access to auto and manual operating modes.

Fully hydraulic movement on clamp die, pressure die and mandrel.

Available pipe material: steel, stainless, aluminum, titanium and brass.

Available pipe shape: Round, Square, Rectangle, Oval, Solid Bar, other profiles.

Equiped with encoder ensures the accuracy and stability of bending.

Equiped with adjustable speed valve on pressure die ensures the synchronization of bending.

Water cooling system ensures the equipment long-time work stably under the high temperature.

CE&ISO 9001: 2000

OPTIONAL of Tube Bender

Automatic pipe rotating(by servo motor) or Automatic pipe feeding(by servo motor)

Anti-clockwise bending

Extra mandrel length

Pipe punching function

PLC controlling

Tie rod bars on bending arm

Feeding length positioner

Mandrel lubrication function

Air cooling device

Cooling Conditioner

Safety mat

TOOL:

STANDARD MATERIAL: 45# STEEL

OPTIONAL MATERIAL:

Ampco Bronze- Mandrel&Wiper die for Stainless Steel Pipe

Nylon- Bending die, Clampe die&Pressure die for Aluminum Pipe

Cr 12-For other pipe material

ACCESSORIES:

TOOL, TOOL BOX, MANUAL OPERATION, INSTALLATION DVD, SPARE PART
