J08 Magnetic Automatic Screen Printing Machine - China

Uses and main technical parameters:

( 1) .

it is used for automatic printing of blankets

2 - working width: 2200mm, 2400mm( according to order)

3 - Overall dimensions( length* width* height) : 73800* 4100* 4460( mm) ( working width 2200mm)

73800* 4300* 4460( mm) ( working width 2400mm)

4 - Number of color: 10( according to order)

5 - Working speed: 6~9 sides/ min

6 - Total motor power: 85kw

7 - Power of magnetic support: 3kw* 10( 10 colors)

Feather:

1 - Cloth feeding part is adopted with center device.

2 - Use double servo- system to drive the belt, it is very accurate.

3 - Adopt permanent magnetic- support which can save power

4 - Use touch screen as operation panel, it is convenient and easy view

5 - Driven by servo- system, the magnetic support is quick and accurate

6 - The vertical movement of printing frame is driven by servo- system which has high working efficiency.

Company Contact:

• Posted By: Toshangx Digital Technology Co., Ltd

• Phone: 8613362029130

• Address: 4th floor,No198,Dongji Road,Qujiang District, Quzhou , China

• Email:

• Website: http://www.dsgxkj.cn

• Business Description: Toshangx Digital Technology Co., Ltd. is located in the Provincial Zone

  of High Technology Development in Quzhou, Zhejiang, China.

  It's main

  business is producing and sale high quality textile printing and dying

  equipment.

  As an industry leader in China, it's featured products

  automatic flat screen printing machine (series J 07 and S 9300) and

  digital ink jet printing machine, are considered as the most accurate

  and efficient machine in domestic market and even can take the place of

  imported products, which has win great fame among customers and

  enterprises.

  To keep the leading pace of innovation and to meet the needs of high quality, Toshangx gathered a big pool of talents from various backgrounds.

  Currently, there are 2 senior NC Engineers, 3 software engineers and 3 mechanical engineers working at the Research and Development department.

  Basing on the existing R&D management and quality control system, following the value of high end, focus, united, breakthrough, focusing on management, innovation, resource, and branding, Toshangx has became a competitive company and will constantly improve its comprehensive abilities.

  So far, Toshangx mainly mass produces automatic flat screen printing machine and develops digital ink jet printing machine.

  In the next five years, TOSHANGX will take the combination of science, technological innovation and management transformation as the strategy to stay leading in the industry field.

  The new high speed ink jet printing machine is currently under research and development, through which TOSHNGX hopes to build a low carbon, environment friendly, more efficient and energy conservative product to extend its business to global market.
