Electric Motor Driven Sand Slurry Pump - China

Introduction:

Slurry pump can be widely used in mines, electric power, metallurgy, coal, environmental protection and other industries transport slurry containing abrasive solid particles.

Such as metallurgical mill pulp conveying, hydraulic ash thermal power plants, coal washery coal slurry and heavy media delivery, dredging river, river dredging, etc.

In the chemical industry, also can carry some corrosive slurry containing crystallization.

Structure:

Single stage, single suction, overhang shaft, centrifugal, double-casing horizontal pump, Wet ends are made of abrasive resistant hard metal or rubber.

Base- High strengthened base is connected with Frame Plate by bolts; The Adjusting Bolt under the Bearing Assembly realize easy adjustment to impeller clearance.

Bearing Assembly:

-High rigidity shaft to handle heavy duty work condition;

-Cartridge bearing assembly jointed with base by bolts;

-Grease Lube bearings fitted in sealed bearing housing, the two labyrinth on both ends prevent the grease from contamination.

Shaft Sleeve - Clearance fit between solid solution treated stainless steel shaft sleeve and shaft as well as the O-rings on both ends prevent the shaft from abrasion and erosion.

Casing - Made of Gray Iron or Ductile Iron, Ribs help casing to stand high pressure.

Impeller - Pump out vanes on both shrouds reduces recirculation and seal pressure.

Wet Ends - Impellers, liners, volutes made of High-Chrome alloy or rubber, both materials are interchangeable.

Specification

Slurry Pump Spares

Pumps spare and parts material :

High chrome alloy: A33, A05, A07, A49, etc.

Natural rubber: R08, R26, R33, R55, etc.

Other material as per requests, like stainless steel, duplex stainless steel, Nickle alloy, Alloy 20, and so on.

Applications

Mining

Coal washery

Power plant

Metallurgy

Petrochemical

Building material

Dredging

Other industrial departments, etc.

This series of pumps are preferred by many customers with special installation requirements and

widely applied in pool.

Its wear-resistant metal liner could handle abrasive slurries with rough particles and high concentration.

Company Information

1 - Company Informations:

Established in 2003, Shijiazhuang Ruite Pump Co., Ltd. is a professional factory being engaged in the design and production of slurry pump, which has passed the ISO9001 certification.

Our products are widely used in mining, metallurgy, coal washing, power plant, sewage water treatment, dredging, and chemical and petroleum industries.

Thanks to the trust and recognition of our clients from many countries, we are becoming one of the most important slurry pump suppliers in China.

After-Sales Service

Warranty

1 - We guarantee our products must meet technical standards and requirements that promised in the contract.

2 - Spared motor and main high-consumable parts will be provided separately so that the machine can be operated in a long term.

Installation and Debugging

Manual, pilot testing data and related soft copies etc.

are provided.

Professional Technical Support

Our company’s technical specialists will help to check and solve our client’s questions and problems via Email and telephone.

Oversea Service Time

Our customers also can directly contact us for consult if necessary.

Our service is 24hors per day

FAQ

1 - Are you a trading company or manufacture?

We are Professional Slurry Pump Manufacturers.

And welcome to our factory to see our product line and our pump quality.

2 - we don't know which model we need, can you help us ?

yes, please let us know the pump capacity, head, then we can help you to calculate .

3 - Is your price the best ?

You get what you pay off.

We supply high effiency good performance slurry pump.

4 - What is the best delivery time?

Within 10-20 days.

5 - Warranty Period?

One year, except spare parts

6 - Why choose us?

13 years experiences professional manufacturer

Good quality with competitive pirce

Professional after-sales service
