Tire Vulcanizing Machine - China

Tire curing press is suitable to press a variety of tires.

Hydraulic

tire curing machine has three major components: host, hydraulic system,

electric control system .

Host is the four column structure, composed by

the beam, base, platform, cylinder, piston, heating plates and other

components.

The hydraulic section made by the high and low pressure

hydraulic pump parts, three-phase AC motor, fuel tank, the combination

valve and manual unloading valve and other accessories.

Type YLL-1000

Total pressure(KN) 1000

Working layer number 2 Layer

Steam chamber internal diameter 830mm

Piston(mm) 285

High pressure(MPa) 16

Low pressure(MPa) 5

Pressure in bladder(MPa) 2.1

Steam working pressure(MPa) 0.6-0.8

Overall dimention 1200*900*2358

Weight(KG) 4500

Type YLL-600

Total pressure(KN) 600

Steam chamber internal diameter 820mm

Piston(mm) 250

High pressure(MPa) 13

Pressure in bladder(MPa) 1.5

Overall dimention 1200*900*2400

Weight(KG) 3200

Type YLL-1400

Total pressure(KN) 1400

Steam chamber internal diameter 1050mm

Piston(mm) 340

High pressure(MPa) 15.5

Overall dimention 1360*1050*3820

Weight(KG) 6000

Type YLL-1600

Total pressure(KN) 1600

Steam chamber internal diameter 1150mm

Piston(mm) 260

Overall dimention 1410*1060*3500

Weight(KG) 7000

Type YLL-2000

Total pressure(KN) 2000

Steam chamber internal diameter 1450mm

Piston(mm) 400

High pressure(MPa) 14

Overall dimention 1500*1500*3200

Weight(KG) 8000
