Casting Flanged Threaded Floating Ball Valve - China

Datian floating ball valves mainly apply to the industries of nature

gas, oil products, chemical industry, metallurgy, city construction,

medicine, environment, foods, etc.

as on / off control units.

Its body

is made of casting or forging; the ball is floating, the ball moves (

floats) downstream to maintain close contact with downstream seat to

form a reliable seal under the medium pressure when closes.

The seat

special design has the wearing complementary structure to ensure safe

reliable sealing and long stable operation of this series of ball valve.

It has the merits of sealing reliability, long life cycle usage and easy

operations.

Applicable Standard

Design Standard: API 6D, ASME B16.34, API 608, BS 5351, MSS SP- 72

Face to Face: API 6D, ASME B16.10, EN 558

End Connection: ASME B16.5, ASME B16.25

Inspection and Test: API 6D, API 598

Products Range

Size: 1/ 2' ~ 10' ( DN15 ~ DN250)

Rating: ANSI 150lb, 300lb, 600lb

Body Materials: Carbon Steel, Stainless Steel, Alloy Steel

Trim: A105+ENP, 13Cr, F304, F316

Operation: Lever, Gear, Electric, Pneumatic, Hydraulic

Design Features

Full port or reduced port

Floating ball design

Blowout- proof stem

Casting or forging body

Fire safe design to API 607/ API 6FA

Anti- static to BS 5351

Cavity pressure self relief

Optional locking device

Company Contact:

• Posted By: Shanghai Datian Valve Pipe Engineering Co.,Ltd.

• Phone: 8602168106365

• Address: No.3223,Zhouzhu Road,Pudong district, Shanghai , China

• Email:

• Website: http://www.datianvalve.com

• Business Description: Shanghai Datian valve, is located at Shanghai, China, owns over 30 years

  experience in valves manufacture and now become Fisher/Descon

  supplier years.

  Further of us pls ref.

  below:

  1 - Best offer due to we are valve manufacturer.

  2 - We own import & export rights.

  3 - API, CE, ISO, TS certificates are available.

  4 - Ball valve, control valve, butterfly valve, check valve, PRV, gate valve, globe valve, etc.

  5 - We own valve utility patent due to strong technician team.

  6 - We are fisher and descon supplier and products exported to more than 50 countries.

  7 - More of us, you could visit the website.

  As one of China s leading m anufacture in valve industry, DATIAN with continuously product development and management creating, continuous product and service quality improvement, targeting on meeting customers complete satisfaction.

  Meanwhile, DATIAN has an active and harmonious working environment, has full employee training system, stimulate employee s self improvement, assume responsibility and achieve self value features.
