Product: DP27 pilot operated pressure reducing valve

Pressure Rating: 1.6- 2.5Mpa Material: Steel WCB

Standard flanges: DIN ANSI JIS JB79

This reducing valve is the new type pilot extra-huge membrane pressure reducing valve developed by our company.

It is greatly improved on basis of normal pressure reducing valve.

The membrane use new material, enlarging the working area, so the slight change of upper pressure or lower pressure can be fed back to membrane of main valve, and adjust the opening of main valve to ensure the constant pressure of lower stream pressure.

Note: A variable rate conical pressure adjustment spring is fitted providing a down stream pressure range of 0.2-17bar g.

main technical parameters and indexes of performance

Nominal pressure PN25

Maximun design pressure(PMA) 25bar g @ 120

Maximun design temperature(TMA) 232 @ 21bar g

Minimun design temperature(TMI) -10

Maximun upstream pressure for saturated steam service(PMO) 17barg

Maximun operating temperature(TMO) 232 @ 21bar g

Minimun operating temperature(TMIO) 0

Maximun differential pressure( PMX ) 17bar

Down stream pressure range 0.2-1.7bar g

Maximum cold hydraulic test pressure 38bar g

material of main component

Name of component Material of component

Valve body, valve cover WCB

Valve seat 2Cr13

valve flap 2Cr13

Valve rod 2Cr13

Membrane Brass

Adjusting spring 60Si2Mn

connecting dimension

DN L H1 H D

15 147 221 133 185

20 154 224 136 185

25 160 235 145 207

32 180 236 156 207

40 200 238 176 255

50 230 246 183 255

65 250 295 200 320

80 310 323 230 350

100 350 340 263 380

125 400 359 306 455

150 450 375 330 500

China Pilot Operated Pressure Reducing Valve
