High Pressure Forged Type Globe Valve - China

High pressure forged type globe valve is a type of adopts a straight-through valve body and controls the media flow by the disc moves up or down.

This straight through stop valve is widely used for control of water, steam, oil and others.

Benefits 1 - Valve bonnet of this stop valve is equipped with an upper seal seat, perfectly meeting the requirements of API and BS standards;

2 - A stud, serving as the middle connection bolt of the valve makes repair and maintenance much easier;

3 - The valve seat is connected by socket weld, it stop any outside leakage ;

4 - Sealed by premium packing, this industrial valve is highly leakage-proof.

Technical specification Size: DN32

Pressure: PN100

Body material: A105

Sealing material: Hard alloy Connection method: Socket welding

Driving method: Handwheel

Design standards: BS1873 Application Chemical industry

Water Works

Power station
