Wafer Lug And Double Flanged Butterfly Valve - China

butterfly valve wafer Lug flange B10W-YX/HJ/SX

Technical Data:

Size: DN40---DN1200

General Design: API1609

Mounting pad: ISO5211

face to face: API1609;EN558 1-20 series etc

flange drilling: DIN 2501 PN10/PN16

inspection and test: API598 Product features:

Wafer, lufg or U type flanged body style between FF or RF flanges

PTFE bushing ensure the maximum shaft support and centralized alignment

360 polished disc assures positive on-off

Hard-backed cartridge seat

One piece shaft, pinned and splined disc.

Universal ISO 5211 mounting pad

Material of construction

parts description Material Specification

1 body cast iron A126 class B

2 bushing PTFE

3 o-ring EPDM

4 shaft stainless steel AISI 316

5 disc stainless steel A351 CF8M

6 seat EPDM

7 Pin Stainless steel AISI316 Hiwa B10 series butterfly valve with hard phenolic seat, pin or splined connection between disc and stem, both wafter and lug style.

​​

Advantages:

light, easy to operate.

High efficiency, high quality, ​​​​​

Company Contact:

• Posted By: Huihua valve industry CO.

• Phone: +865336077206

• Address: Floor block B International, ZIBO-ZHANGDIAN , China

• Email:

• Website: http://www.hiwa.cc

• Business Description: Huihua valve industry co., main range of manufacturing are: Butterfly valve, resilient and metal seated gate valve, swing check valve, lift check valve, wafer check valve, Y-strainer, globe valve, angle valve, ball valve and foot valve etc.

  High quality and No.

  1 after-sale service get our valves good markets nearly every parts of the world, such as U.

  S.

  A., Chile, Australia, S.

  Africa, Germany, Spain, Norway, Korea, Taiwan, Singapore, India, Norway, Saudi Arabia, Kuwait, Lebanon etc.

  With years of exporting experience, we are good at manufacturing to standards: GB, DIN, ANSI, BS, AS, JIS, ISO, MSN, API, KS etc.

  Or make to clients' special requirements.

  Acquirement of TUV CE0036&ISO9002 and SGS ISO9001 certificates makes Huihua set up a full set of Quality Managing System.

  "quality is life" Huihua will always ensure supplying standard high quality valves to our clients
