Lc Pc Upc Apc Single Mode Sx Fiber Optical Connector - China

Lc/pc/upc/apc single mode sx fiber optical connector

description

fiber optic connectors are ultra reliable components featuring low insertion loss and return loss.

they come with your choice of simplex or duplex cable configuration and are made to conform to iec, telcordia gr-326-core standard.

the performance of the fiber optic connector has been carefully designed to meet the iec standards, gr-326-core, in the test of optical characteristics, vibration test, thermal cycling, impact resistance, salt spray erosion, thermal aging, humidity resistance and others.

features 1 - low insertion loss and back reflection loss 2 - ferrule end surface pre-domed

3 - boots in a variety colors

4 - telcordia style boots 5 - free-floating ceramic ferrule

6 - the connector can be supplied as a pre-assenbled one piece or one piece or as connector kit.

7 - clips are avaliable for sc and lc duplex connector.

applications

1 - ftth

2 - wan

3 - lan

4 - telecommunication

5 - catv

6 - optical distribution frame ferrule hole sizes

singlemode 125.0+1/-0um, concentricity<=1.0um

125.5+1/-0um, concentricity<=1.0um 126.0+1/-0um, concentricity<=1.0um multimode; 125um concentricity <=3um

127um concentricity <=3um

128um concentricity <=3um
