Lan Cable Cat5e Utp Ethernet Communication - China

price: 18.00 Dollar US$

Lan Cable Cat5e Utp Ethernet Communication

Products Photos Catalog Lan Cable Cat5e Utp Photos Catalog

Description

Rated temperature 75ºC

Standard UL444, TIA/EIA568, ISO/IEC11801

24 AWG Wire Gauge

A single bare copper conductor

Insulating high density polyethylene

Fill as needed

Color code belt as needed

Core color code as required

Line of 25-100

Sheath PVC/LLDPE/LSZH(as required)

Tear the rope as needed

Electrical properties

1.0~ 100.0mhz characteristic impedance (ohms) 100±15

1.0~ 350.0mhz delay (ns/100m) ≤45

At 20ºC, the maximum dc resistance (ohms/km) of the conductor is less than or equal to 93.8

Conductor resistance unbalance (%) ≤1.0

Line-to-ground capacitance unbalance (PF/100m) ≤330

Application

100 Base - T4

100 Base - TX

100 VG - AnyLAN

155 Mbps ATM

622 Mbps ATM


Company Contact:


  • Phone: 86-575-85550857

  • Address: JINGTANG ROAD, XUANCHENG CITY ANHUI PROVINCE P.R.CHINA, P.R.CHINA , China

  • Email: Email


Published date: January 18, 2021

  • Business Description: General Clad is a technology driven company specialized in developing and producing bimetallic material such as copper clad steel (CCS), copper clad aluminum (CCA) and Aluminum Clad Steel (ACS) as well as CCS fine wire (CCSF) Ability to develop multilayer bimetallic materials.

    With it′s production site in China and two sales office for EU and American market, General Clad is offering it s bimetallic material for clients from more than 20 countries in the world every year.
