High Quality Pvc Coated Welded Mesh - China

PVC Coated Welded Mesh

PVC coated welded mesh is a type of wire mesh that has been coated in polyvinyl chloride (PVC) plastic.

The PVC coating provides additional corrosion resistance and protection against wear and tear compared to uncoated wire mesh.

Especially, the galvanized welded mesh is coated with two layers of PVC and Zinc which is tightly bonded to the wire by a heat process.

They are double protection.

Not only does the vinyl coating seal protect the wire from water and other corrosive elements, but also the underlying mesh is also protected by good zinc coating.

PVC coat make the welded mesh longer working life, and more beautiful with different colors(Green, black, yellow, blue, white or other colors at customers request.

).

It is commonly used in construction and industrial applications, such as fencing, barrier reinforcement, and flooring.

Additionally it is also often used in agriculture, as well as security enclosures, storage shelves and Racking protection.

PVC coated welded mesh is available in a variety of gauge sizes and mesh configurations to suit different needs.

Specification

PVC coated welded mesh is available in a variety of gauge sizes and mesh configurations to suit different needs.

Mesh Size Wire Dia before & after PVC coat

In mm Mesh Size Before Coat After Coat

6.4mm 1/4 Inch 0.56- 0.71mm 0.90- 1.05mm

9.5mm 3/8 Inch 0.64 - 1.07mm 1.00 - 1.52mm

12.7mmm 1/2 Inch 0.71 - 1.65mm 1.10 - 2.20mm

15.9mm 5/8 Inch 0.81 - 1.65mm 1.22 - 2.30mm

19.1mm 3/4 Inch 0.81 - 1.65mmm 1.24 - 2.40mm

25.4 × 12.7mm 1 × 1/2 Inch 0.81 - 1.65mm 1.24 - 2.42mm

25.4mm 1 Inch 0.81 - 2.11mm 1.28 - 2.90mm

38.1mm 1 1/2 Inch 1.07 - 2.11mm 1.57 - 2.92mm

25.4 × 50.8mm 1 × 2 Inch 1.47 - 2.11mm 2.00 - 2.95mm

50.8mm 2 Inch 1.65 - 2.77mm 2.20 - 3.61mm

76.2mm 3 Inch 1.90 - 3.50mm 2.50 - 4.36mm

101.6mm 4 Inch 2.20 - 4.00mm 2.85 - 4.88mm

Roll width 0.5m-2.5m, according to request.

Roll length 10m, 15m, 20m, 25m, 30m, 30.5m, according to request.

Advantage

Dense use, no peeling or peeling.

Many years longer than uncoated wires.

A variety of colors are available, including black, yellow and light gray.

Customs color

Provide a variety of materials, such as carbon steel and galvanized steel.

Prevent corrosion

Application

Widely used in the fishing, industry, agriculture, construction, transport and mining.

Such as machine protection cover, ranch fender, garden fence, window protection fence, passage fence, fowl cage, egg basket, foodstuffs basket, ect.
