Sintered Filter Heng Shui - China

As a new filter product, sintered filter is combined with varying sizes

and materials of multi layers mesh which are cut by laser cutting

machine with high precision and then overlapped by sintered in the

vacuum.

According to its material, it can be divided into stainless

steel sintered filter disc, galvanized sintered filter disc and copper

sintered filter disc.

Generally, it has several layers mainly including

protecting layer, filtration control layer, scattered skeleton layer,

skeleton supporting layer.

Because of its special structure, this type of filter overcomes the weakness of the low intensity, poor rigidity, mesh instability enough, deformation easily.

So it is an ideal filter to be used in every industry with high pressure and high temperature.

Specification

Filter materials: copper mesh, stainless steel mesh, brass mesh, etc.

Filtration rate: 0.2 μm - 300 μm.

Diameter: 200 - 3000 mm.

Thickness: 1.7 mm, 2.5 mm, 3.5 mm.

Weaving type: plain weave, twill weave, dutch weave, etc.

Filter shapes: round, ring, square, rectangular, oval, etc.

Layers: five layers or multi layers.

Process technique: spot welded, edge covering and sintering.

A round sintered filter manufactured with aluminum frame.

SF- 01: Sintered filter can be installed with aluminum frame to be more durable.

One hand holds a multi layers sintered filter.

SF- 02: Sintered filters made of multi layers different kinds of mesh.

Five cylindrical sintered filters stand in a row.

SF- 03: Cylindrical galvanized sintered filter.

Two round sintered filters discs made of copper mesh.

SF- 04: Copper sintered filter.

Two round sintered filters and one square sintered filter on the white background.

SF- 05: Sintered filters can be made of different shapes.

One sintered filter made of black wire cloth in the surface.

SF- 06: Sintered filters can be made of various materials.

Features

Accurate filter rating.

Good strength.

Works long time.

Repeatedly cleaning and usage.

Application

The sintered filter is widely used in a wide range of industries, for instance petroleum, chemical fiber, chemical, energy, aviation, security, environmental protection, medicine and electricity, etc.

Company Contact:

• Posted By: Boegger Industrial Limited Heng Shui A

• Phone: 863185111380

• Address: East industrial Zone, Anping, Hebei, China., anping , China

• Email:

• Website: https://www.meshfilter.org

• Business Description: Established in 2000, Boegger has developed rapidly in manufacturing and supplying various kinds of filters during the several years.

  Now, Boegger has become one of the leading manufactures of metal mesh filters.

  Mesh filters are mainly used to remove your undesired contaminants from liquid, gas, solid or air.

  At last, you can achieve what you want without any impurities.

  We produce almost any types of filters with high quality and high precision to meet different filtration requirements.

  So when you are troubled by foreign matters, Boegger can offer you an effective solution.

  Various Products

  We can offer you a wide range of filters with different specifications, the main products are as follows: cylindrical filter, conical filter, basket filter, perforated filter tube, sintered filter, knitted wire mesh filter, hydraulic oil filter, air filter, panel filter.

  The filter features outstanding rigidity and strength.

  And these filters with long service life not only can withstand high temperature and high pressure, but also can be manufactured with multi layers mesh with spot welded edge.

  Furthermore, it can be designed cleanable and reusable.
