Shanghai Factory Best Sell Smd Aluminum Led Screen 4 81 - China

Overview

Specifications

Place of Origin:

Shanghai, China (Mainland)

Brand Name:

Leado

Model Number:

outdoor SMD P4.81

Usage:

Outdoor

Tube Chip Color:

Full Color

Display Function:

video, image, text, message and so on

Pixels:

4.81mm

Screen Dimension:

Customized

Name:

smd aluminum led screen 4.81

Other name:

Shanghai factory smd aluminum led screen 4.81

Certificate:

CE ROHS FCC

Brightness:

≥6000cd/Sq.

m.

Led chip:

Epistar

Warranty:

2years

Application:

Live Events Led Display

Module size:

250*250mm

Life span:

100000hours

Viewing angle:

H140° V140°

Packaging & Delivery

Packaging Details:

smd aluminum led screen 4.81 packing: pearl wool + carton + wooden box or flight case

Delivery Detail:

Shipped in 15 days after payment

Shanghai factory Best sell smd aluminum led screen 4.81 Product Description Specification of smd aluminum led screen 4.81

No.

specs outdoor full color PH4.81

1 Pixel structure SMD, 2727

2 Pixel pitch 4.81mm 3 Pixel density 43000dots/Sq.

m.

4 Luminance ≥6000cd/Sq.

m.

5 Module dimension 250mm(W) * 250mm(H)

6 Module resolution 52 pixel(W) *52pixelmm(H)

7 Module weight 400g

8 Cabinet dimension 500 * 500mm or other

9 Cabinet area 0.25 sq.

meter or other

10 Screen weight 40~60kg/m2

11 Optimal visual distance > 5m

12 Visual angel 140 degree (H/V)

13 Max power consumption 1600w /Sq.

m.

14 Average power consumption 800w /Sq.

m.

15 Brightness adjustment Adjust according to the enviroment

brightness software (0%-100%adjustable)

16 Drive mode 1/13 dynamic scan, constant current

17 Input voltage AC 110~220 volts

18 Operation temperature -10° C~ +50° C

19 Operation humidity 10%~90%

20 Input signal DVI, MPG, AVI, WMV, RM etc.

21 Control system DVI card + master control card + receiver card

22 lifetime (50% brightness) >100, 000 hrs

23 Malfunction dot rate 1/10000

24 Cabinet material Epoxy paint coated Cold rolled steel iron/Aluminum 25 Data interconnection UTP Cat 5/Optical Fiber

26 Application: Rental installation available
