Slit Lamp Ophthalmic - India

Slit lamp - ophthalmic

technical details: -

type : stereoscopic microscope

eye pieces : 10x

objective : 1x, 1.6x

total magnification: 10x, 16x

diameter of visual field: 18mm, 14.5mm, 9mm

illumination

slit projection magnification: 2/3x

slit width : continuous from 12mm to 0mm (at 10mm slit becomes a circle)

slit length : continuous from 12mm to 1mm or aperture settings at 9, 8, 5, 3, 2, 1 and 0.2mm dia.

slit angle : 0deg.

to 180deg.

with horizontal scanning capability

slit inclination : 0, 5deg., 10deg., 15deg.

and 20deg.

steps.

filters : blue, red free, nd, heat-absorbing no filter

lamp : 6v, 20w halogen lamp

base

longitudinal movement : 95mm

lateral movement : 105mm

fine base movement : 15mm

(with joystick)

vertical movement : 32mm

chin rest

vertical movement : 82mm

fixation target : luminous target

red led

power

input (primary) : ac 220v / 110v

frequency : 50/60hz

output (secondary) : main bulb 2.4v, 6.0v for brightness levels

power consumption : 26v a

dimensions & weight

table model : 560 x 407mm

unit model : 375 x 335mm

weight : 21kg

standard accessories

dust cover, replacing lamp for illumination unit
