Auto Rice Beans Weighing Filling Packing Line - China

Application

This machine is applied to quantitative packing powdery or granular materials into various bags.

Such as: spice, salt, sugar, rice, fodder, seed, washing powder, etc.

This machine is widely used in foodstuff, pharmacy, seed process and chemical etc industries.

Features

1 - Computer control, manual bag-feeding, automatic count.

2 - Electronic scale weighing, double-vibration feeding, high filling accuracy, stability is Good, save raw material and manpower.

3 - The production line is consist of charging machine, weighing and filling machine, convey machine, heat seal machine, industry seam machine and electric cabinet

4 - The weighing control system adopts PLC control system and is designed according to IP54(dustproof and waterproof) requirement;

5 - The unit consists of fully automatic weighing machine, conveyor, bag sewing machine, air pump);

6 - Optional Parts: multiple devices available for choose

such as conveyor, bag sewing machine, air pump).

Technical parameters

Single-hopper Weighing range 1-10kg

Drive mode Pneumatic

Max weighing weight 10kg

Weighing accuracy ±0.2%-0.4%

Weighing speed 900-1200 bags/hour

Power/ Current 6kw/16A

Air supply pressure 0.36Mpa

Single -hopper capacity 10L

Weighing Mode Sensor

Hopper type Suspension type

Frequency/ Voltage 50Hz 60Hz/220V 380V

Power supply mode 3-phase 5-wire system

Dimension (L*W*H) 4200*1750*3320

Auto Rice Beans Weighing Filling Packing Line
