Automatic One Step Injection Blow Molding Machine For Small Bottles - China

JASU ISB800-3 is a one stage injection blow

molding machine (not from performs) for PET,

PC and PP containers.

The machine is capable

of accepting 6 cavities.

Fully automatic, single step, injection

stretch blow moulding machines produce

containers from 0.3 litres up to 1 litres.

Widely used for manufacturing bottles for

pharmaceutical, healthcare, food, beverages,

cosmetics and other applications.

A horizontal three station indexing head

contains injection, blowing and outfeed

stations which operate simultaneously in a

fully automatic cycle.

Highly efficient with

low energy comsuption.

Suitable for use with a wide range of

thermoplastic materials, including PET, PP

and PC.

All machines are built to ISO9001 standards

and CE certified.

Machine Features

*The machine provides fast molding

performance without scrap or connecting lines

on bottle bottom or side.

*Maximum uniformity of bottle weight,

thickness and volume.

*Bottle body, neck and mouth can be varied to

meet specific requirements.

*Extremely smooth and elegant bottle surface

is ideal for high-quality and high-price

packaging.

*This high production machine is capable of

producing bottles in multiple cavities at one

time.

*Suitable for various materials, such as PET,

PE, PP, PS, PC, PETG, PMMA, etc.

*producing various types of bottles.

*Multiple-stage injection

Injection Blow Molding Machine Parameter

Item Unit Machine Type

IB500-2 ISB800-3

ISB800-4

Injection Part Screw Diameter mm 50

40 40

Screw L/D Ratio L/D 23.2 23

23

Screw Speed r/min 0-185 0-220

0-220

Injection Weight G 390

195 195

Injection Pressure Kg/cm2 1700

1504 1504

Max.

Hydraulic Pressure Kg/cm 140

140 140

Plasticizing Capacity g/s 24

14 14

Injection Rate g/s 128 140

140

Clamping Part Blow Clamping Force Kn

150 80 80

Clamp Tonnage Kn 600 400

400

Wheel Diameter mm 800

800

Max.

Height of Bottle mm 400

145

Open Vertical Mode Trip mm 430

430 430

Others Max.

Pump Pressure Mpa 16

16 16

Motor Oil Kw 18.5 18.5

18.5

Electric Power Kw 16 13

13

Tank Volume L 400 400

Dimension of Machine m

4.1x1.45x3.1

Machine Weight Ton 5 5

5
